System And Components
8N-9453 PUMP GP-FUEL INJECTIONPART OF 1W-2364 PUMP GP-GOV DRV,FUEL INJ & TFR
Group No: 8N-9453
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3L5987 | 1 COVER | 1 | |
| 8S5388 | GASKET | 1 | |
| 2A0762 | 2 BOLT (1/4-20X0.625-IN) | 1 | |
| 9S4191 | 3 PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6N2574 | 4 COVER | 1 | |
| 4N1636 | GASKET | 1 | |
| 8H9204 | 5 WASHER-FELT (19/32X7/8X5/16-IN THK) | 8 | |
| 7E5085 | 6 BUSHING-TERMINAL | 8 | |
| 9S8008 | 7 PLUG (1-1/16-12-THD) | 2 | |
| 3D2824 | SEAL-O-RING | 2 | |
| 7N2694 | 8 BRACKET AS-CONTROL | 1 | |
| 6N9655 | 9 PIN | 1 | |
| 7N2693 | 10 SPRING-TORSION | 1 | |
| 1T0284 | 11 BOLT-SOCKET HEAD (5/16-18X1-IN) | 1 | |
| 4N1572 | 12 LINK-RACK | 1 | |
| 4N0900 | 13 RACK-REGULATOR | 1 | |
| 4N0901 | RACK-REGULATOR | 1 | |
| 1M1077 | 14 SEAL-O-RING (26.64MM ID) | 8 | |
| 6N7829 | 15 PUMP GP-FUEL INJECTION | 8 | |
| 5M2697 | 16 SPACER (1.026X1.285X0.17-IN THK) | 8 | |
| 2M4208 | SPACER (1.027X1.285X0.174-IN THK) | 8 | |
| 2M4209 | SPACER (1.027X1.285X0.178-IN THK) | 8 | |
| 2M4210 | SPACER (1.027X1.285X0.182-IN THK) | 8 | |
| 2M4211 | SPACER (1.027X1.285X0.186-IN THK) | 8 | |
| 2M4212 | SPACER (1.027X1.285X0.19-IN THK) | 8 | |
| 5M2691 | SPACER (1.027X1.285X0.194-IN THK) | 8 | |
| 5S7189 | SPACER (1.027X1.285X0.198-IN THK) | 8 | |
| 4N0779 | 17 HOUSING GP-FUEL PUMP | 1 | |
| 8N6981 | 18 LIFTER AS | 8 | |
| 4W8140 | 19 CAMSHAFT-FUEL PUMP | 1 | |
| 5P0537 | 20 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 6N2837 | 21 COVER | 1 | |
| 1W1401 | 22 SCREW-RACK STOP | 1 | |
| 6F5926 | 23 NUT | 1 | |
| 6N2833 | LOCK-SETSCREW | 1 | |
| 1L5316 | PIN-SPRING | 1 | |
| 1H3943 | 24 WASHER | 1 | |
| 9N6495 | 25 SPACER (26.08X32.64X4.216-MM THK) | 8 | |
| 9N6496 | SPACER (26.08X32.64X4.115-MM THK) | 8 | |
| 6N0540 | 26 PLUG | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 7B2742 | 27 BOLT (1/4-20X1.25-IN) | 1 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 7S5757 | 28 RING-RETAINING | 1 | |
| 4N9767 | 29 ADAPTER-GOVERNOR DRIVE | 1 | |
| 8H3127 | BOLT (1/4-20X0.75-IN) | 2 | |
| 4N9766 | 30 PINION-GOVERNOR DRIVE | 1 | |
| 6N2834 | 31 WASHER | 1 | |
| 6N2838 | 32 SHAFT | 1 | |
| 6N6926 | 33 SPRING | 1 | |
| 6N2839 | 34 SHAFT | 1 | |
| 7J9018 | 35 BOLT-SOCKET HEAD (10-24X0.625-IN) | 2 | |
| 6N2836 | 36 LEVER-RACK STOP | 1 | |
| 0310215 | 37 BOLT-LOCKING (1/4-20X0.625-IN) | 1 | |
| 4N0907 | 38 LEVER-SHUTOFF | 1 | |
| 4N0905 | 39 GEAR-BEVEL (42-TEETH) | 1 | |
| 4N0776 | 40 RETAINER | 1 | |
| 0S1618 | 41 BOLT (5/16-18X1-IN) | 3 | |
| 5M6214 | 42 PLUG (1/8-27 PTF) | 1 | |
| 6N2835 | 43 LEVER-SHUTOFF | 1 | |
| 0S1616 | 44 BOLT (1/4-20X1-IN) | 1 |
