System And Components
1W-3221 LINES GP-TURBOCHARGER OILS/N 08Z29143-99999
Group No: 1W-3221
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C9098 | 1 TUBE AS-SUPPLY (OIL) | 1 | |
| 1A2029 | 2 BOLT (3/8-16X1.125-IN) | 7 | |
| 5M2894 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 7N8875 | 4 GASKET | 1 | |
| 3J7354 | 5 SEAL-O-RING | 1 | |
| 7N7559 | 6 GASKET | 1 | |
| 0S1591 | 7 BOLT (3/8-16X1.5-IN) | 2 | |
| 8M5253 | 8 SEAL-O-RING | 1 | |
| 7N7674 | 9 ELBOW-DRAIN | 1 | |
| 1S4810 | 10 GASKET-OIL DRAIN | 1 | |
| 6N6033 | 11 CLIP | 2 | |
| 7W4064 | 12 TUBE AS-DRAIN (OIL) | 1 | |
| 9S4185 | 13 PLUG (3/4-16-THD) | 1 | |
| 3K0360 | 14 SEAL-O-RING | 2 | |
| 0307948 | 15 ELBOW | 1 | |
| 1D4716 | 16 NUT-FULL (5/16-18-THD) | 1 | |
| 5M6213 | 17 PLUG-PIPE (1/4-18-THD) | 1 | |
| 4W1512 | 18 SUPPORT AS-PUMP | 1 | |
| 5H4279 | PLUG-CUP | 1 | |
| 8M5248 | 19 SEAL-O-RING | 2 | |
| 9S8002 | 20 PLUG (7/16-20-THD) | 1 | |
| 9M4849 | 21 SEAL-O-RING | 1 | |
| 4M6480 | 22 GASKET | 1 | |
| 9N5328 | 23 ADAPTER | 1 | |
| 0L1143 | 24 BOLT (3/8-16X2.5-IN) | 1 | |
| 0S1617 | 25 BOLT (5/16-18X0.75-IN) | 1 | |
| 9M1974 | 26 WASHER-HARD (8.8X16X2-MM THK) | 2 |
