System And Components
4P-8484 LINES GP-TURBOCHARGER OILS/N 08Z66679-88499
Group No: 4P-8484
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1571 | 1 BOLT (3/8-16X1.75-IN) | 2 | |
| 1S6595 | 2 GASKET-OIL SUPPLY | 1 | |
| 1S4810 | 3 GASKET-OIL DRAIN | 1 | |
| 0S1594 | 4 BOLT (3/8-16X1-IN) | 2 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 9S4185 | 6 PLUG (3/4-16-THD) | 2 | |
| 3K0360 | 7 SEAL-O-RING | 2 | |
| 9M4849 | 8 SEAL-O-RING | 1 | |
| 1A2029 | 9 BOLT (3/8-16X1.125-IN) | 3 | |
| 9M4584 | 10 CONNECTOR | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 8M5253 | 11 SEAL-O-RING | 1 | |
| 0S1608 | 12 BOLT (3/8-16X3.75-IN) | 1 | |
| 4W1512 | 14 SUPPORT AS-PUMP | 1 | |
| 8T6765 | 14A PLUG-PIPE (1/4-18-THD) | 1 | |
| 5H4279 | PLUG-CUP | 1 | |
| 9S8002 | 15 PLUG (7/16-20-THD) | 1 | |
| 3J7354 | 16 SEAL-O-RING | 1 | |
| 8N1149 | 17 ELBOW | 1 | |
| 0L2070 | 18 BOLT (3/8-16X2.25-IN) | 1 | |
| 8M5248 | 19 SEAL-O-RING | 2 | |
| 4M6480 | 20 GASKET | 1 | |
| 1044600 | 21 TUBE AS-OIL SUPPLY | 1 | |
| 7C5870 | 22 TUBE AS-DRAIN | 1 | |
| 9M8406 | 23 CLIP (LOOP) | 1 | |
| 1H5514 | 24 BOLT (5/16-18X1.625-IN) | 1 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 1 |
