System And Components
6N-3447 AFTERCOOLER GP-WATERS/N 08Z27183-44119
Group No: 6N-3447
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0343557 | 1 BOLT-LOCKING (3/8-16X1.125-IN) | 4 | |
| 9M1974 | 2 WASHER-HARD (8.8X16X2-MM THK) | 24 | |
| 1261689 | 3 COVER AS | 1 | |
| 1H6525 | 4 INSERT | 4 | |
| 1H5514 | 5 BOLT (5/16-18X1.625-IN) | 18 | |
| 8T6764 | 6 PLUG-PIPE (1/8-27-THD) | 1 | |
| 7W0491 | 7 CORE AS-AFTERCOOLER | 1 | |
| 6L1648 | 8 SEAL-O-RING | 2 | |
| 9L5903 | 9 ADAPTER | 2 | |
| 2W3679 | GASKET | 2 | |
| 0310219 | 10 BOLT-LOCKING (3/8-16X1.75-IN) | 4 | |
| 4N0205 | SPACER (0.42X0.75X0.6-IN THK) | 4 | |
| 5M2894 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 5S6735 | 12 GASKET | 2 | |
| 8T6762 | 13 PLUG-PIPE (1/2-14-THD) | 1 | |
| 1261688 | 14 HOUSING | 1 | |
| 9L5908 | 15 GASKET | 2 | |
| 9L2625 | 16 FLANGE-TRANSFER PIPE | 1 | |
| 1N9372 | GASKET-FLANGE (AIR INLET) | 1 | |
| 0L2070 | 17 BOLT (3/8-16X2.25-IN) | 4 | |
| 1D4538 | 18 BOLT (5/16-18X2.25-IN) | 6 | |
| 6N5457 | 19 PLATE | 2 | |
| 8T6765 | 20 PLUG-PIPE (1/4-18-THD) | 1 |
