System And Components
3T-8363 CONTROL GP-TRANSMISSION HYDS/N 3HB1-511; 3KB1-99999
Group No: 3T-8363
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3D4197 | 1 COVER | 1 | |
| 2P9217 | 2 CYLINDER GP-SHIFT | 1 | |
| 6P5032 | 3 VALVE GP-TRANSMISSION CONTROL | 1 | |
| 0S0509 | 4 BOLT (3/8-16X0.75-IN) | 2 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 3B4506 | 6 LOCKWASHER | 4 | |
| 6T4958 | 7 HARNESS AS | 1 | |
| 5B3718 | SEAL-O-RING | 1 | |
| 1A2029 | 8 BOLT (3/8-16X1.125-IN) | 4 | |
| 0S1571 | 9 BOLT (3/8-16X1.75-IN) | 4 | |
| 1D4566 | 10 BOLT (1/2-13X3.5-IN) | 1 | |
| 1D4719 | NUT-FULL (1/2-13-THD) | 1 | |
| 3B4508 | LOCKWASHER | 1 | |
| 4B4280 | WASHER (13.5X27X2.5-MM THK) | 1 | |
| 9S5222 | SPACER (12.73X18.87X26.19-MM THK) | 1 | |
| 2S1381 | 11 SPRING | 1 | |
| 8S0669 | 12 SLEEVE | 1 | |
| 8M5010 | 13 SEAL-O-RING | 2 | |
| 8M8157 | 14 SEAL-O-RING | 2 | |
| 5S0899 | 15 DETENT AS | 1 | |
| 1S3206 | 16 BEARING AS-NEEDLE | 2 | |
| 8P4764 | 17 PIN | 1 | |
| 8B4037 | 18 WASHER (0.766X1.75X0.083-IN THK) | 2 | |
| 9H0223 | 19 SEAL-LIP TYPE | 2 | |
| 1P8247 | 20 SHAFT | 1 | |
| 8S6377 | 21 PIN-LOCK | 1 | |
| 0S1571 | 22 BOLT (3/8-16X1.75-IN) | 2 | |
| 5M2894 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8M8514 | 24 SEAL-O-RING | 6 | |
| 5S3632 | 25 SLEEVE | 3 | |
| 9P2182 | 26 GEAR (33 TEETH) | 1 | |
| 7M2082 | 27 GASKET | 1 | |
| 1B9575 | 28 BOLT (5/16-18X1.56-IN) | 4 | |
| 1T0738 | WASHER (8.4X19X1.83-MM THK) | 4 | |
| 3T0565 | 29 COVER | 1 | |
| 9G1813 | 30 SWITCH AS (SLAVE & SYNCH.) | 1 | |
| 0L1352 | 31 BOLT (3/8-16X3.25-IN) | 4 | |
| 2J6356 | 32 RING-RETAINING | 1 | |
| 1P8260 | 33 CAMSHAFT | 1 | |
| 5S7954 | 34 LEVER AS | 1 | |
| 9S2825 | 35 DOWEL | 1 | |
| 8P8907 | 36 PLATE AS | 1 | |
| 3H1118 | PIN-SPRING | 1 | |
| 7J2036 | 37 SEAL-O-RING | 1 | |
| 8S5575 | 38 SEAL-LIP TYPE | 1 | |
| 8P8764 | 39 SPACER | 4 | |
| 2M4453 | 40 SEAL-O-RING | 4 |
