System And Components
4P9891 CYLINDER BLOCK GPTYPE 1. ENGINE S/N 99W2827-UP
Group No: 4P9891
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E4939 | 1 CYLINDER BLOCK AS | 1 | |
| 9M1974 | 2 WASHER-HARD | 8 | |
| 5P8245 | 3 WASHER | 2 | |
| 1A2029 | 4 BOLT | 1 | |
| 7X7731 | 5 PLUG-PIPE | 2 | |
| 9S4191 | 6 PLUG-O-RING | 6 | |
| 2W2940 | 7 PLUG-OIL MANIFOLD | 8 | |
| 7N2044 | 8 DOWEL | 2 | |
| 8T6762 | 9 PLUG-PIPE | 3 | |
| 5M2894 | 10 WASHER | 9 | |
| 7N2047 | 11 DOWEL | 3 | |
| 7X4805 | 12 SEAL-O-RING | 3 | |
| 7E4069 | 13 JET AS-COOLING | 8 | |
| 0T0102 | 14 BOLT | 8 | |
| 7N2048 | 15 BEARING-CAMSHAFT | 10 | |
| 4N0683 | 16 DOWEL | 2 | |
| 8T6763 | 17 PLUG | 20 | |
| 0S1595 | 18 BOLT | 2 | |
| 8T0099 | 19 DOWEL | 16 | |
| 7N5641 | 20 PLUG-MANIFOLD | 2 | |
| 7N2049 | 21 DOWEL | 8 | |
| 5P0840 | 22 SEAL-O-RING | 16 | |
| 1007886 | 23 GASKET-PLATE | 8 | |
| 9Y1485 | 24 PLATE-SPACER | 8 | |
| 5F9657 | 25 SEAL-O-RING | 4 | |
| 5P8210 | 26 SEAL-O-RING | 2 | |
| 1B2790 | 27 BOLT | 8 | |
| 7C3722 | 28 RETAINER AS-JET (EACH INCLUDES) | 8 | |
| 6V3537 | DOWEL | 1 | |
| 8N8056 | 29 COVER | 1 | |
| 6V3348 | 30 SEAL-O-RING | 8 | |
| 4W4814 | 31 ADAPTER | 1 | |
| 8T2929 | 32 SEAL (63.2MM)OD | 1 | |
| 8T2928 | 33 SEAL (53.1MM)OD | 1 | |
| 0336042 | 34 SEAL-O-RING | 6 | |
| 8N8056 | 35 COVER | 1 | |
| 1A2029 | 36 BOLT | 1 | |
| 5M2894 | 37 WASHER | 1 |
