System And Components
8N9794 BELT TIGHTENER GPENGINE S/N 99W1-UP
Group No: 8N9794
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W8461 | 1 COVER | 1 | |
| 0L2070 | 2 BOLT (3/8-16X2.25IN) | 2 | |
| 7W8460 | 3 WASHER-RETAINING | 1 | |
| 2H3755 | 4 BOLT (5/16-18X.625IN) | 4 | |
| 9M1974 | 5 WASHER-HARD (2MM THK) | 4 | |
| 2N8374 | 6 GASKET | 1 | |
| 8H9789 | 7 BALL BEARING | 2 | |
| 8N9419 | 8 SPACER | 1 | |
| 5S2106 | 9 SEAL-LIP | 1 | |
| 5M2057 | 10 SEAL-O-RING | 1 | |
| 8N9410 | 11 SPACER | 1 | |
| 8B1419 | 12 PIN-CLEVIS | 2 | |
| 3B4617 | 13 COTTER | 2 | |
| 7N5959 | 14 SPRING | 2 | |
| 0S1594 | 15 BOLT (3/8-16X1IN) | 1 | |
| 5M2894 | 16 WASHER (2.5MM THK) | 3 | |
| 2M2742 | 17 PLATE-RETAINER | 1 | |
| 8N9411 | 18 PULLEY-IDLER | 1 | |
| 4B4550 | 19 FITTING-RELIEF | 1 | |
| 3B6552 | 20 ELBOW | 1 | |
| 3B8686 | 21 FITTING-HYDRAULIC | 1 | |
| 2V0460 | 22 HOSE AS | 1 | |
| 4D8123 | 23 CLIP (7.94 MM ID) | 1 | |
| 1D4574 | 24 BOLT (1/2-13X6IN) | 2 | |
| 8S3887 | 25 BOLT (7/16-14X11IN) | 2 | |
| 5P8245 | 26 WASHER (3MM THK) | 2 | |
| 0S1587 | 27 BOLT (1/2-13X1.75IN) | 1 | |
| 1W0535 | 28 BRACKET AS | 1 | |
| 1S9209 | SHAFT-TIGHTENER | 1 | |
| 8H9189 | DOWEL | 1 | |
| 1W0533 | 29 ARM AS-TIGHTENER | 1 | |
| 5M7937 | DOWEL | 1 | |
| 4S5367 | BUSHING AS | 1 | |
| 5B9318 | BALL | 1 | |
| 1W0537 | 30 BRACKET AS | 1 | |
| 1S9209 | SHAFT-TIGHTENER | 1 | |
| 8H9189 | DOWEL | 1 | |
| 7K8790 | 31 SPACER | 2 | |
| 2A4639 | 32 BOLT (3/8-16X1.625IN) | 2 | |
| 9Y5010 | 33 ADAPTER-GREASE | 1 |
