System And Components
7N3978 DRIVE GP-ACCESSORYLOWER FLYWHEEL HOUSING
Group No: 7N3978
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1378290 | 1 ADAPTER AS | 1 | |
| 7N3011 | BEARING-SLEEVE | 1 | |
| 3F5792 | 2 SEAL-O-RING (129.77MM ID) | 1 | |
| 1378185 | 3 CAGE AS | 1 | |
| 7N3011 | BEARING-SLEEVE | 1 | |
| 3F6795 | DOWEL | 2 | |
| 1215796 | 4 SHAFT AS | 1 | |
| 1095724 | SEAL GP-LIP TYPE | 1 | |
| 2G8135 | 5 YOKE | 1 | |
| 7N8525 | 6 WASHER-THRUST | 2 | |
| 1215790 | 7 GEAR AS-CLUSTER | 1 | |
| 1026299 | BEARING-SLEEVE | 1 | |
| 1026294 | 8 SHAFT-IDLER | 1 | |
| 5D9514 | 9 BOLT | 1 | |
| 7N3006 | 10 WASHER-THRUST | 2 | |
| 5P8245 | 11 WASHER (3MM THK) | 5 | |
| 5P8247 | 12 WASHER-HARD (3.5MM THK) | 3 | |
| 8M5255 | 13 SEAL-O-RING (120.24MM ID) | 1 | |
| 0S1587 | 14 BOLT (1/2-13X1.75IN) | 4 | |
| 5P2546 | 15 BOLT-12 POINT HEAD (7/16-14X1.25IN) | 12 | |
| 1D4574 | 16 BOLT (1/2-13X6IN) | 1 | |
| 5D3954 | 17 STUD-TAPERLOCK | 2 | |
| 2D8806 | 18 STUD-TAPERLOCK | 4 | |
| 1F7958 | 19 NUT-FULL (1/2-13 THD) | 4 | |
| 1095722 | 20 SEAL-LIP | 1 | |
| 4K0367 | 21 NUT (5/8-11 THD) | 2 | |
| 1V6341 | 22 SEAL (30.15MM OD) | 2 | |
| 7N2865 | 23 GEAR (73 TEETH) | 1 | |
| 1095721 | 24 SEAL-DIRT | 1 | |
| 5R7137 | 25 WASHER-SEAL (1.27MM THK) | 4 | |
| 2K7471 | 26 LOCKNUT (1-14 THD) | 1 | |
| 3K5234 | 27 WASHER-HARD (6.0MM THK) | 1 |
