System And Components
2W0731 AFTERCOOLER GP-TREATED WATERENGINE S/N 99W1-3252
Group No: 2W0731
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W5456 | 1 CORE AS-AFTERCOOLER | 1 | |
| 0314630 | 2 BOLT-SELF LOCKING | 1 | |
| 9M1974 | 3 WASHER | 14 | |
| 6V1454 | 4 SEAL-O-RING | 6 | |
| 1M7913 | 5 RING-NUT LOCK | 1 | |
| 5M7423 | 6 SEAL-O-RING | 4 | |
| 1W1258 | 7 HOUSING-FRONT | 1 | |
| 2W1382 | 8 ELBOW | 1 | |
| 1W1260 | 9 HOUSING-REAR | 1 | |
| 1W1253 | 10 GASKET | 1 | |
| 4N0684 | 11 PIN-DOWEL | 2 | |
| 1T0720 | 12 BOLT-12 POINT HEAD | 12 | |
| 5M2894 | 13 WASHER | 40 | |
| 4P1567 | 14 GASKET | 1 | |
| 0L1143 | 15 BOLT | 28 | |
| 5F4899 | 16 BOLT | 2 | |
| 8N2409 | 17 ADAPTER | 2 | |
| 7M9909 | 18 SEAL-O-RING | 2 | |
| 1W5728 | 19 SLEEVE | 2 | |
| 2B0858 | 20 PLUG-PIPE | 4 | |
| 1A9066 | 21 GASKET | 1 | |
| 1W4955 | 22 SPACER | 28 | |
| 7W0229 | 23 CONNECTOR AS | 1 | |
| 7W0227 | PLUG | 1 | |
| 4W3108 | VALVE AS-LINE | 1 | |
| 3J5390 | 24 PLUG | 1 |
