System And Components
1N4813 SHIELD GP-EXHAUSTENGINE S/N 99W1-2689
Group No: 1N4813
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E7876 | 1 SHIELD | 2 | |
| 0302135 | 2 BOLT-LOCKING | 58 | |
| 9M1974 | 3 WASHER-HARD (2MM THK) | 18 | |
| 7W8131 | 4 SUPPORT AS | 2 | |
| 4K9097 | NUT-WELD (5/16-18 THD) | 5 | |
| 7W8130 | SUPPORT-SHIELD | 1 | |
| 7W7336 | 5 GUIDE-SHIELD | 4 | |
| 7W4880 | 6 SHIELD AS-MANIFOLD | 2 | |
| 7W6286 | 7 SHIELD AS-MANIFOLD-RH | 1 | |
| 7W4878 | 8 SHIELD AS-MANIFOLD | 2 | |
| 7W4959 | 9 SHIELD AS-MANIFOLD | 2 | |
| 7W7335 | 10 BRACKET | 2 | |
| 1W9739 | 11 SHIELD AS-MANIFOLD | 2 | |
| 1W9741 | 12 SHIELD AS-MANIFOLD | 2 | |
| 7E7871 | 13 SHIELD AS-TURBOCHARGER | 1 | |
| 7E7873 | 14 SHIELD AS-TURBOCHARGER | 1 | |
| 7E7875 | 15 SHIELD AS-TURBOCHARGER | 1 | |
| 7E7870 | 16 SHIELD AS-TURBOCHARGER | 1 | |
| 7E7874 | 17 SHIELD AS-TURBOCHARGER | 1 | |
| 7W4961 | 18 SHIELD AS-MANIFOLD | 2 | |
| 7W4876 | 19 SHIELD AS-MANIFOLD | 2 | |
| 7W7528 | 20 SHIELD AS-MANIFOLD | 1 | |
| 7W6179 | 21 SHIELD AS-MANIFOLD-LH | 1 | |
| 7W7530 | 22 SHIELD AS-MANIFOLD | 1 | |
| 7E7872 | 23 SHIELD AS-TURBOCHARGER | 1 | |
| 9N0869 | 24 WASHER (2MM THK) | 52 | |
| 6V8189 | 25 NUT (5/16-18 THD) | 12 | |
| 7E7877 | 26 PLATE | 2 |
