System And Components
4P3742 SHIELD GP-EXHAUSTENGINE S/N 99W2690-UP
Group No: 4P3742
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E4352 | 1 WASHER-HARD | 10 | |
| 0302135 | 2 BOLT-LOCKING | 37 | |
| 9M1974 | 3 WASHER-HARD (2MM THK) | 15 | |
| 7W8131 | 4 SUPPORT AS | 2 | |
| 4K9097 | NUT-WELD (5/16-18 THD) | 5 | |
| 7W7336 | 5 GUIDE-SHIELD | 4 | |
| 7W4880 | 6 SHIELD AS-MANIFOLD | 1 | |
| 9N0869 | 7 WASHER | 12 | |
| 4P4464 | 8 SHIELD AS-MANIFOLD | 1 | |
| 7W4959 | 9 SHIELD AS-MANIFOLD | 2 | |
| 7W7335 | 10 BRACKET | 1 | |
| 1W9739 | 11 SHIELD AS-MANIFOLD | 1 | |
| 1W9741 | 12 SHIELD AS-MANIFOLD | 1 | |
| 4P4461 | 13 SHIELD AS-MANIFOLD (LH) | 1 | |
| 4P4462 | 14 SHIELD AS-MANIFOLD (RH) | 1 | |
| 4P6931 | 15 ANGLE-LH | 1 | |
| 4P6933 | 16 ANGLE-RH | 1 | |
| 7W4876 | 17 SHIELD AS-MANIFOLD | 2 | |
| 7W4961 | 18 SHIELD AS-MANIFOLD | 2 |
