System And Components
1W-8055 LINES GP-TURBOCHARGER OILS/N 08Z33309-34032
Group No: 1W-8055
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B1915 | 1 BOLT (3/8-16X1.375-IN) | 2 | |
| 1S6595 | 2 GASKET-OIL SUPPLY | 1 | |
| 1S4810 | 3 GASKET-OIL DRAIN | 1 | |
| 0S1594 | 4 BOLT (3/8-16X1-IN) | 2 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 0S1617 | 6 BOLT (5/16-18X0.75-IN) | 1 | |
| 9M1974 | 7 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1D4716 | 8 NUT-FULL (5/16-18-THD) | 1 | |
| 6N6033 | 9 CLIP | 2 | |
| 1W8057 | 10 TUBE AS-TURBOCHARGER | 1 | |
| 9S4185 | 11 PLUG (3/4-16-THD) | 1 | |
| 3K0360 | 12 SEAL-O-RING | 2 | |
| 8M5253 | 13 SEAL-O-RING | 1 | |
| 0L1352 | 14 BOLT (3/8-16X3.25-IN) | 1 | |
| 5M6213 | 15 PLUG-PIPE (1/4-18-THD) | 1 | |
| 4W1512 | 16 SUPPORT AS-PUMP | 1 | |
| 8T6765 | PLUG-PIPE (1/4-18-THD) | 1 | |
| 5H4279 | PLUG-CUP | 1 | |
| 8M5248 | 17 SEAL-O-RING | 2 | |
| 3J7354 | 18 SEAL-O-RING | 1 | |
| 9S8002 | 19 PLUG (7/16-20-THD) | 1 | |
| 9M4849 | 20 SEAL-O-RING | 1 | |
| 4M6480 | 21 GASKET | 1 | |
| 9N5328 | 22 ADAPTER | 1 | |
| 0L1143 | 23 BOLT (3/8-16X2.5-IN) | 1 | |
| 0307943 | 24 ELBOW | 1 | |
| 7W9046 | 25 TUBE AS-SUPPLY | 1 | |
| 1A2029 | 26 BOLT (3/8-16X1.125-IN) | 3 |
