System And Components
1W-3216 LINES GP-AIRS/N 08Z52194-99999
Group No: 1W-3216
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N1287 | 1 ELBOW-FLARED | 1 | |
| 2B2404 | 2 CLIP | 2 | |
| 0S1608 | 3 BOLT (3/8-16X3.75-IN) | 2 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 7C8787 | 5 TUBE AS-CONTROL | 1 | |
| 3J7352 | 6 CONNECTOR | 1 | |
| 3J7354 | 7 SEAL-O-RING | 1 | |
| 5F4899 | 8 BOLT (3/8-16X5.5-IN) | 1 | |
| 9S7083 | 9 GASKET-INLET | 1 | |
| 1A2029 | 10 BOLT (3/8-16X1.125-IN) | 4 | |
| 7W6899 | 11 PIPE-AIR INLET | 1 | |
| 4L8337 | 12 SEAL-O-RING | 4 | |
| 0L1351 | 13 BOLT (3/8-16X0.875-IN) | 2 | |
| 7W3145 | 14 PLATE | 1 | |
| 7W6900 | 15 ELBOW | 1 | |
| 2H3755 | 16 BOLT (5/16-18X0.43-IN) | 2 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 7W1944 | 17 RETAINER | 1 |
