5T-0800 TANK & FILTER GP-HYDRAULICS/N 6EB1-600; 6GB1-99999

Group No: 5T-0800
Part NumberPart NameQty
5D19011 WASHER (106.5X126.5X2.5-MM THK)1
9M73942 LEVER1
5D19023 COVER-HYDRAULIC CAP1
1L50724 DOWEL1
4J37545 CAP-FILLER1
4B9782BALL1
4J3816PLATE1
4J3815GASKET1
1M86496 RING-RETAINING1
6D07457 STRAINER AS1
8D43808 PLUNGER1
7B28059 RING-LOCK (RETAINING)1
5T080510 BAFFLE1
0T010211 BOLT (3/8-16X0.625-IN)5
9L913212 WASHER-HARD (10.2X25.5X2.5-MM THK)21
5T000313 ELBOW1
2H633814 SEAL-O-RING2
0S158515 BOLT (1/2-13X1.5-IN)6
5P824516 WASHER-HARD (13.5X25.5X3-MM THK)6
2G935417 COVER AS1
5D421818 BLOCK1
2G935619 GASKET1
3B055120 PLUG-PIPE1
9S999321 ADAPTER1
2M9189GASKET1
5D035322 BOLT-LOCKING (3/8-16X1-IN)74
5M2894WASHER-HARD (10.2X18.5X2.5-MM THK)74
1D4717NUT (3/8-16-THD)74
2J311823 BOLT-LOCKING (3/8-16X1.25-IN)13
5T113224 COVER1
5J3316GASKET1
5P129625 HOSE1
5P171726 CLAMP-HOSE4
5T113627 ELBOW1
5P850228 PADLOCK GP1
6V5874COVER1
5P8500KEY2
2Y4071PADLOCK (BRAZIL USAGE)1
3G815229 FILTER GP-OIL1
6G1249GASKET1
5H8985PIN-SPRING1
030853730 BOLT-LOCKING (3/8-16X1.5-IN)8
5M289431 WASHER-HARD (10.2X18.5X2.5-MM THK)12
2G822732 VALVE GP-BREAKER RELIEF1
3J1907SEAL-O-RING1
5T079933 TANK AS-HYDRAULIC1
5T775541 SCREEN AS1
0S0509BOLT (3/8-16X0.75-IN)4
2J266842 COVER-FLANGE1
1P4579FLANGE-HALF2
4J0524SEAL-O-RING1
0S158543 BOLT (1/2-13X1.5-IN)8
5P824544 WASHER-HARD (13.5X25.5X3-MM THK)8
5T776145 TUBE AS1
5F8000SEAL-O-RING1
5T113046 TUBE AS1
2H6338SEAL-O-RING1
6J107947 RETAINER-GLASS1
6J1080GROMMET1
6J1081GLASS-SIGHT1
6J1126PLATE-INDICATOR1
4J826548 NUT (3/8-16-THD)6
0S158849 BOLT (3/8-16X1.25-IN)3
