System And Components
8J-5920 VALVE GP-MAIN CONTROLS/N 6EB1-492; 6GB1-547
Group No: 8J-5920
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9S8005 | 1 PLUG (3/4-16-THD) | 2 | |
| 3K0360 | SEAL-O-RING | 2 | |
| 7M8433 | 2 SPACER (20.6X31X1.6-MM THK) | 1 | |
| 6J1889 | 3 SEAL-U-CUP | 3 | |
| 8J5963 | 4 SEAL-LIP TYPE | 3 | |
| 1A2029 | 5 BOLT (3/8-16X1.125-IN) | 6 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 8J9223 | 6 COVER | 3 | |
| 9S8004 | 7 PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6J3134 | 8 SEAL-O-RING | 1 | |
| 3G1854 | 9 VALVE GP-SEQUENCE | 1 | |
| 4J0520 | SEAL-O-RING | 2 | |
| 5K0216 | 10 SEAL-O-RING | 2 | |
| 8J4463 | 11 WASHER (20.4X30.73X2.54-MM THK) | 1 | |
| 8J2097 | 12 SPRING (OUTER) | 1 | |
| 8J9422 | 13 SPRING (INNER) | 1 | |
| 8J9225 | 14 RETAINER | 1 | |
| 8J9226 | 15 HOUSING | 1 | |
| 3S7005 | 16 RING-LOCK | 1 | |
| 9J5622 | 17 SPRING | 1 | |
| 8T1360 | 18 RING-RETAINING | 2 | |
| 9J6442 | 19 SPRING | 1 | |
| 8J8660 | 20 HOUSING-EJECTOR | 1 | |
| 9J5621 | 21 DETENT-EJECTOR | 1 | |
| 9S8006 | 22 PLUG (7/8-14-THD) | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 8J2086 | 23 SPRING | 1 | |
| 9J5618 | 24 WASHER (0.805X1.58X0.15-IN THK) | 1 | |
| 8J2085 | 25 POPPET | 1 | |
| 6V6234 | 26 SETSCREW-SOCKET (1/4-28-THD) | 1 | |
| 8J4456 | 27 RETAINER | 1 | |
| 8J4454 | 28 RING | 1 | |
| 8J4455 | 29 BALL | 4 | |
| 9J7913 | 30 SPACER (1.36X1.61X0.46-IN THK) | 1 | |
| 5F7054 | 31 SEAL-O-RING | 2 | |
| 9J5620 | 32 RETAINER | 1 | |
| 9J5619 | 33 RETAINER | 1 | |
| 9J7914 | 34 VALVE GP | 1 | |
| 9S8005 | 35 PLUG (3/4-16-THD) | 2 | |
| 3K0360 | SEAL-O-RING | 2 | |
| 3B1915 | 36 BOLT (3/8-16X1.375-IN) | 18 | |
| 5M2894 | 37 WASHER-HARD (10.2X18.5X2.5-MM THK) | 30 | |
| 1P4577 | 38 FLANGE-HALF | 12 | |
| 8J4443 | 39 COVER | 1 | |
| 1P4578 | 40 FLANGE-HALF | 2 | |
| 1U1019 | 41 RETAINER | 1 | |
| 1P4579 | 42 FLANGE-HALF | 2 | |
| 0S1585 | 43 BOLT (1/2-13X1.5-IN) | 4 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 3H2549 | 44 SHIM (0.254-MM THK) | 1 | |
| 3J7473 | SHIM (0.12-MM THK) | 6 | |
| 8J4436 | 45 CAP | 1 | |
| 7F9067 | 46 PIN | 1 | |
| 8J4437 | 47 SPRING (INNER) | 1 | |
| 9J4726 | 48 VALVE GP | 1 | |
| 6J2561 | 49 VALVE | 1 | |
| 4J0522 | 50 SEAL-O-RING | 1 | |
| 8J4446 | 51 SPRING (OUTER) | 1 | |
| 8J4457 | 52 RETAINER | 1 | |
| 8T1360 | 53 RING-RETAINING | 2 | |
| 8J4455 | 54 BALL | 4 | |
| 8J4454 | 55 RING | 1 | |
| 8J4456 | 56 RETAINER | 1 | |
| 7K2558 | 57 WASHER-FELT (1.5X2.06X0.312-IN THK) | 1 | |
| 8J8655 | 58 VALVE GP-AIR CONTROL | 1 | |
| 2M9780 | 59 SEAL-O-RING | 1 | |
| 8J8660 | 60 HOUSING-EJECTOR | 1 | |
| 9J6442 | 61 SPRING | 1 | |
| 3S7005 | 62 RING-LOCK | 1 | |
| 9J6441 | 63 SPRING | 1 | |
| 8J9224 | 64 RETAINER | 1 | |
| 5K0216 | 65 SEAL-O-RING | 1 | |
| 4J5907 | 66 BOLT (3/8-16X1.375-IN) | 6 | |
| 0S1619 | 67 BOLT (3/8-16X3-IN) | 8 | |
| 3H5368 | 68 BOLT (7/16-14X1.375-IN) | 4 | |
| 5P8244 | WASHER-HARD (12X22.5X2.5-MM THK) | 4 |
