System And Components
4W6425 AIR COMPRESSOR GP*RPART OF 1N2981 AIR COMPRESSOR
Group No: 4W6425
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N7448 | 1 GASKET-AIR COMPRESSOR | 1 | |
| 7N7447 | 2 HEAD AS-COMPRESSOR | 1 | |
| 0S1619 | 3 BOLT (3/8-16X3IN) | 5 | |
| 4W9479 | 4 MANIFOLD-EXHAUST | 1 | |
| 1S7107 | GASKET | 1 | |
| 0L1352 | 5 BOLT (3/8-16X3.25IN) | 1 | |
| 5M2894 | WASHER (2.5MM THK) | 1 | |
| 2B2695 | 6 BOLT (5/16-18X.875IN) | 2 | |
| 3B4505 | 7 LOCKWASHER (.097IN THK) | 8 | |
| 7N7450 | 8 COVER-UNLOADER | 1 | |
| 7N7451 | GASKET-UNLOADER | 1 | |
| 0S1615 | 9 BOLT (1/4-20X.75IN) | 2 | |
| 3B4504 | LOCKWASHER (.077IN THK) | 2 | |
| 2B0858 | 10 PLUG-PIPE | 1 | |
| 7N7441 | 11 COVER-AIR COMPRESSOR | 1 | |
| 7N7442 | GASKET-AIR COMPRESSOR | 1 | |
| 1B8714 | 12 KEY-WOODRUFF | 1 | |
| 0344160 | 13 BOLT-LOCKING (5/16-18X1.0) | 4 | |
| 5M6214 | 14 PLUG-PIPE | 1 | |
| 0S1617 | 15 BOLT (5/16-18X.75IN) | 6 | |
| 7N7439 | 16 PLATE-COVER | 1 | |
| 7N7440 | GASKET-AIR COMPRESSOR | 1 | |
| 8H9789 | 17 BALL BEARING | 2 | |
| 4W6706 | 18 CRANKSHAFT-AIR COMPRESSOR | 1 | |
| 4W6681 | 19 CRANKCASE AS | 1 | |
| 1A2029 | 20 BOLT (3/8-16X1.125IN) | 6 | |
| 3B4506 | LOCKWASHER | 6 | |
| 4B4845 | 21 PLUG (PIPE) | 2 | |
| 7N7445 | 22 CYLINDER BLOCK | 1 | |
| 7N7446 | GASKET-AIR COMPRESSOR | 1 | |
| 4W9489 | 23 LOCKRING | 1 | |
| 7N7435 | KIT-AIR COMPRESSOR | 1 | |
| 4P6409 | KIT-PIN | 1 | |
| 1440503 | KIT-PISTON & RING | 1 | |
| 1382887 | KIT-ROD & BEARING | 1 | |
| 1440502 | RING KIT-PISTON | 1 |
