System And Components
1W8347 AFTERCOOLER GP-WATERTYPE 2
Group No: 1W8347
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B9575 | 1 BOLT | 12 | |
| 9M1974 | 2 WASHER | 26 | |
| 8N8099 | 3 COVER-AFTERCOOLER | 1 | |
| 5M6213 | 4 PLUG | 1 | |
| 9F8999 | 5 BOLT | 4 | |
| 5M2894 | 6 WASHER | 18 | |
| 1W0512 | 7 COVER-AFTERCOOLER | 1 | |
| 7W0688 | 8 GASKET-ADAPTER | 2 | |
| 8N8100 | 9 ADAPTER | 1 | |
| 2S6160 | 10 WASHER-HARD | 1 | |
| 4N9008 | 11 GASKET | 2 | |
| 6L9589 | 12 GASKET | 2 | |
| 5D9844 | 13 BOLT-SELF LOCKING | 1 | |
| 4W4775 | 14 ADAPTER | 2 | |
| 4N4193 | 15 ADAPTER | 2 | |
| 9M7002 | 16 SEAL-O-RING | 2 | |
| 5P7204 | 17 SEAL-O-RING | 2 | |
| 1W4879 | 18 CORE AS-AFTERCOOLER | 1 | |
| 8N8098 | 19 HOUSING-AFTERCOOLER | 1 | |
| 5M6214 | 20 PLUG-PIPE | 2 | |
| 2N8204 | 21 GASKET | 6 | |
| 3J5389 | 22 PLUG | 1 | |
| 0310219 | 23 BOLT-SELF LOCKING | 10 | |
| 5B5620 | 24 BOLT | 21 | |
| 2B0858 | 25 PLUG-PIPE | 1 | |
| 1B9575 | 26 BOLT | 1 | |
| 1D4717 | 27 NUT | 4 | |
| 0310219 | 28 BOLT-SELF LOCKING | 1 | |
| 5M2894 | WASHER | 1 | |
| 3J5389 | 29 PLUG | 1 | |
| 5M6214 | 30 PLUG-PIPE | 1 |
