System And Components
7N9339 DRIVE GP-FANTYPE 2
Group No: 7N9339
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5S9062 | 1 SPACER | 1 | |
| 5S2106 | 2 SEAL-LIP | 1 | |
| 0T0065 | 3 BOLT | 6 | |
| 7N8827 | 4 HUB | 1 | |
| 3L1425 | 5 BALL BEARING | 1 | |
| 2D4867 | 6 FITTING-HYDRAULIC | 1 | |
| 1D4719 | 7 NUT (1/2-13 THD) | 4 | |
| 4N2370 | 8 ADAPTER-FAN | 1 | |
| 1H5403 | 9 BOLT | 2 | |
| 5S7264 | WASHER-RETAINING 5.56MM(.219IN.)THK | 1 | |
| 5P7979 | BOLT-LOCKING | 2 | |
| 7N2900 | WASHER-RETAINING 12.7MM(.50IN.)THK | 1 | |
| 9F4446 | 10 SEAL-O-RING | 1 | |
| 7N3949 | 11 V-BELT SET | 1 | |
| 7N3947 | 12 PULLEY-FAN DRIVE | 1 | |
| 2P2243 | 13 SPACER | 1 | |
| 8H9789 | 14 BALL BEARING | 1 | |
| 4B4550 | 15 FITTING-RELIEF | 1 | |
| 6N7688 | 16 BRACKET AS-FAN | 1 | |
| 6N2538 | 17 BRACKET-FAN ADJUSTMENT | 1 | |
| 8L5213 | 18 BOLT | 1 | |
| 1D4717 | NUT | 1 | |
| 6N2547 | 19 ADAPTER-FAN BRACKET | 1 | |
| 9L0553 | 20 STUD-TAPERLOCK | 4 | |
| 1F7960 | WASHER | 4 | |
| 0S1594 | 21 BOLT | 2 |
