System And Components
1238291 LINES GP-AIR
Group No: 1238291
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7L0520 | 1 STUD-TAPERLOCK | 4 | |
| 2N2766 | 2 LOCKNUT (3/8-16 THD) | 7 | |
| 4N6145 | 3 SUPPORT-MANIFOLD | 1 | |
| 1D4706 | 4 BOLT (3/8-16X6IN) | 1 | |
| 0S1608 | 5 BOLT (3/8-16X3.75IN) | 3 | |
| 0S1591 | 6 BOLT (3/8-16X1.5IN) | 6 | |
| 2W7553 | 7 MANIFOLD | 1 | |
| 3E7428 | 8 PLUG-PIPE | 2 | |
| 6L8562 | 9 STUD-TAPERLOCK (3/8-16X1.77IN) | 4 | |
| 2N2765 | 10 BOLT-HIGH TEMPERATURE | 3 | |
| 4K5175 | 11 BOLT-12 POINT HEAD | 2 | |
| 2M0849 | 12 WASHER (5MM THK) | 2 | |
| 8N0879 | 13 CLAMP | 4 | |
| 1238281 | 14 TUBE AS-EXHAUST | 1 | |
| 1238282 | 15 TUBE AS-EXHAUST | 1 | |
| 4N2564 | 16 GASKET-AFTERCOOLER | 1 | |
| 7W6492 | 17 PLUG-PIPE (1/2 IN-14 THD) | 1 | |
| 7N9669 | 18 PIPE-OUTLET | 1 | |
| 1254641 | 19 SEAL-O-RING | 2 | |
| 1254642 | 20 SEAL-O-RING | 2 | |
| 9F8596 | 21 LUG | 2 | |
| 1A2029 | 22 BOLT (3/8 X 16 X 1.125IN) | 2 | |
| 5M2894 | 23 WASHER (2.5MM THK) | 14 | |
| 0S1594 | 24 BOLT (3/8-16X1IN) | 6 | |
| 6N2331 | 25 GASKET | 1 | |
| 5L8854 | 26 RING-SEALING | 2 | |
| 8T6765 | 27 PLUG-PIPE | 3 | |
| 4N1010 | 28 SUPPORT-ELBOW | 1 | |
| 4N2565 | 29 PLATE-MANIFOLD | 1 | |
| 0S1590 | 30 BOLT (3/8 X 16 X 2IN) | 2 | |
| 9L6657 | 31 COUPLING-EXHAUST | 1 | |
| 9N1081 | 32 ADAPTER-TRANSFER PIPE | 1 | |
| 4N6143 | 33 SPACER-MANIFOLD SUPPORT | 1 |
