System And Components
9Y3322 SHIELD GP-MANIFOLDFOR USE WITH FIRE PUMP ENGINE
Group No: 9Y3322
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9Y4575 | 1 SHIELD AS-TURBOCHARGER | 2 | |
| 0S1618 | 2 BOLT | 20 | |
| 9M1974 | 3 WASHER | 56 | |
| 1B5354 | 4 NUT-FULL | 38 | |
| 1W0464 | 5 SHIELD AS-TURBOCHARGER (LH) | 1 | |
| 6V2712 | 6 STUD | 18 | |
| 0S1594 | 7 BOLT | 12 | |
| 5M2894 | 8 WASHER | 12 | |
| 1W0458 | 9 SHIELD AS-TURBOCHARGER (RH) | 1 | |
| 1W3397 | 10 PLATE | 2 | |
| 1W0460 | 11 SHIELD AS-TURBOCHARGER (RH) | 1 | |
| 1W0456 | 12 SHIELD AS-MANIFOLD (RH) | 1 | |
| 8N7954 | 13 PLATE | 2 | |
| 5P9959 | 14 BOLT | 4 | |
| 1W0462 | 15 SHIELD AS-MANIFOLD (LH) | 1 | |
| 1W0466 | 16 SHIELD AS-TURBOCHARGER (LH) | 1 | |
| 5P4116 | 17 WASHER | 6 |
