System And Components
2W4910 CLUTCH GP-PART 2 OF 2PART OF 2W4911 POWER TAKE-OFF-REAR
Group No: 2W4910
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1L7796 | 15 KEY | 1 | |
| 1L5015 | 16 PLATE-CLUTCH | 1 | |
| 4L3527 | 17 PLATE-CLUTCH DRIVING | 3 | |
| 3N8125 | 18 PLATE AS-PRESSURE | 1 | |
| 3N8124 | SPRING-LOCKPIN | 1 | |
| 3N8123 | LOCKPIN | 1 | |
| 1L4863 | 19 WASHER-SPRING | 8 | |
| 6L3972 | 20 PIN | 4 | |
| 4H0002 | 21 LEVER | 4 | |
| 6L3961 | 22 COTTER | 4 | |
| 4B4721 | 23 LINK | 8 | |
| 6L3967 | 24 PIN | 8 | |
| 6L3964 | 25 COTTER | 8 | |
| 4B4716 | 26 COLLAR AS-SLEEVE | 1 | |
| 0L0639 | 27 BOLT | 2 | |
| 2L6267 | LOCKNUT | 2 | |
| 4B4758 | SHIM | 2 | |
| 6B3223 | 28 CUP-BEARING | 2 | |
| 4B7270 | 29 CONE-BEARING | 2 | |
| 4B4764 | 30 NUT | 1 | |
| 4B4773 | 31 LOCK | 1 | |
| 5L3486 | 32 RING-DRIVE | 1 | |
| 3H9571 | 33 PLATE-CENTER | 2 | |
| 3H9572 | 34 RING-ADJUSTMENT | 1 | |
| 3H9574 | 35 SLEEVE | 1 | |
| 4B4792 | 36 YOKE AS | 1 | |
| 0S1591 | 37 BOLT | 2 | |
| 3B4506 | LOCKWASHER | 2 | |
| 6L5151 | 38 KEY-WOODRUFF | 2 | |
| 4B4770 | 39 SHAFT-GOVERNOR CONTROL | 1 | |
| 5B2404 | 40 RETAINER-BEARING | 1 | |
| 5B2407 | 41 LOCK | 1 | |
| 0S1617 | 42 BOLT | 1 | |
| 3F9556 | 43 LOCKWASHER | 1 | |
| 3F3728 | 44 RING-SNAP | 1 |
