System And Components
7T8472 CONTROL GP-BRAKE-PART 1 OF 29W1617-PAGE 167
Group No: 7T8472
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3W4566 | 1 SHAFT | 1 | |
| 8T0192 | 2 BOLT | 1 | |
| 4L6454 | 3 BOLT | 4 | |
| 8T4896 | 4 WASHER-HARD (2.5MM THK) | 8 | |
| 4L9337 | 5 BOLT | 2 | |
| 9W9690 | 6 ROD AS | 1 | |
| 6B6684 | 7 NUT-FULL | 6 | |
| 5K1719 | 8 ROD END-YOKE | 1 | |
| 0S0175 | 9 PIN-CLEVIS | 2 | |
| 7X0293 | 10 BOLT (3/8-16X4.75IN) | 2 | |
| 8T9378 | 11 BOLT (3/8-16X4IN) | 2 | |
| 9W2550 | 12 LEVER | 1 | |
| 1B8706 | 13 KEY-WOODRUFF | 2 | |
| 9W1617 | 14 VALVE GP-BRAKE CONTROL | 1 | |
| 8M5254 | 15 SEAL-O-RING | 3 | |
| 6V2761 | 16 BOOT-ROD END | 1 | |
| 4D4065 | ROD END-BEARING | 1 | |
| 3J3122 | 17 STUD | 1 | |
| 6F7010 | 18 END-ROD | 1 | |
| 9W2548 | 19 LEVER | 1 | |
| 9F7781 | 20 SPRING | 1 | |
| 1K6872 | 21 LOCKNUT | 1 | |
| 7T0904 | 22 BOLT-ANCHOR | 1 | |
| 9G5211 | SPACER | 1 | |
| 6Y6779 | 23 BRACKET | 1 | |
| 9W2549 | 24 LEVER | 1 | |
| 3W0556 | 25 SHAFT | 1 | |
| 8T1177 | 26 BEARING-ROLLER | 2 | |
| 4H1477 | 27 PIN | 1 | |
| 3B4617 | 28 COTTER | 2 | |
| 6V8801 | 29 NUT | 3 | |
| 8F7702 | 30 SEAL-LIP TYPE | 4 | |
| 3F0566 | 31 WASHER | 1 | |
| 9W9688 | 32 STUD | 2 | |
| 8T9378 | 33 BOLT | 2 | |
| 8T9379 | 34 BOLT (3/8-16X4.25IN) | 1 | |
| 7X0575 | WASHER-HARD (5MM THK) | 1 |
