System And Components
1N4455 LINES GP-AIR COMPRESSOR
Group No: 1N4455
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N5645 | 1 TUBE AS-OUTLET | 1 | |
| 7K1517 | 2 ELBOW | 2 | |
| 2N1287 | 3 ELBOW-FLARED | 2 | |
| 1N4458 | 4 TUBE AS | 1 | |
| 1W4785 | 5 TUBE AS | 1 | |
| 5K9240 | 6 ELBOW-FLARED | 1 | |
| 1P7125 | 7 GOVERNOR AS | 1 | |
| 2S2923 | 8 COVER-GOVERNOR | 1 | |
| 9F2247 | 9 PLUG | 4 | |
| 1D4541 | 10 BOLT | 2 | |
| 1D4716 | NUT-FULL | 2 | |
| 9M1974 | 11 WASHER | 6 | |
| 5K9238 | 12 CONNECTOR-FLARED | 1 | |
| 8N0449 | 13 TUBE AS-INLET | 1 | |
| 1B3057 | 14 CLIP | 1 | |
| 1N4457 | 15 BRACKET | 1 | |
| 1A9579 | 16 BOLT | 2 | |
| 3S8536 | SPACER | 2 | |
| 6K1972 | 17 ELBOW-FLARED | 1 | |
| 2N1287 | 18 ELBOW-FLARED | 1 | |
| 0305817 | 19 HOSE AS-HYDRAULIC | 1 | |
| 5K9244 | 20 ELBOW-FLARED | 1 | |
| 3B6552 | 21 ELBOW | 1 | |
| 5M6214 | PLUG-PIPE | 1 | |
| 5F5434 | 22 VENT AS | 1 | |
| 6K8079 | 23 CONNECTOR-FLARED | 1 | |
| 3B7764 | 24 BUSHING | 1 | |
| 9M0402 | KIT-GOVERNOR OVERHAUL (INCL GROMMETS, SPRING, | 1 |
