System And Components
8N2283 LINES GP-TURBOCHARGER OILALSO AN ATTACHMENT
Group No: 8N2283
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B7182 | 1 BOLT 32MM(1.261 IN)LG | 1 | |
| 1P1255 | 2 GASKET-OIL DRAIN | 1 | |
| 0L1143 | 3 BOLT | 2 | |
| 7W3044 | 4 TUBE AS-DRAIN | 1 | |
| 6N6033 | 5 CLIP | 4 | |
| 0S1617 | 6 BOLT | 2 | |
| 1D4716 | NUT-FULL | 2 | |
| 9M1974 | WASHER | 4 | |
| 1N3537 | 7 TUBE AS-OIL SUPPLY | 1 | |
| 8M0505 | 8 CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 5M6213 | 9 PLUG | 2 | |
| 5P8245 | 10 WASHER | 1 | |
| 8M5248 | 11 SEAL-O-RING | 2 | |
| 1B4367 | 12 BOLT 76.2MM(3.0 IN)LG | 1 | |
| 1D4585 | BOLT 82.55MM(3.25 IN)LG | 1 | |
| 9Y4380 | RETAINER | 1 | |
| 5P8247 | 13 WASHER-HARD | 1 | |
| 5M2894 | 14 WASHER | 4 | |
| 3J5390 | 15 PLUG | 1 | |
| 0S1619 | 16 BOLT | 2 | |
| 9M4849 | 17 SEAL-O-RING | 1 | |
| 8M4438 | 18 SEAL-O-RING | 1 | |
| 0S1585 | 19 BOLT | 1 | |
| 8M4446 | 20 SEAL-O-RING | 1 | |
| 4W9655 | 21 SUPPORT | 1 | |
| 4B3388 | 22 BOLT 28MM(1.103 IN)LG | 1 | |
| 8H9788 | 23 GASKET | 1 |
