System And Components
7E8541 AIR COMPRESSOR GP*RSINGLE CYLINDER
Group No: 7E8541
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C0561 | 1 CRANKCASE AS | 1 | |
| 7C0562 | 2 CRANKSHAFT-COMPRESSOR | 1 | |
| 7C0563 | 3 ROD & PISTON AS | 1 | |
| 7C0564 | 4 COVER AS-END | 1 | |
| 7C0565 | 5 SEAL-END COVER | 1 | |
| 2B2695 | 6 BOLT | 4 | |
| 3B4505 | 7 LOCKWASHER | 8 | |
| 7C0566 | 8 BEARING | 2 | |
| 7C0577 | 9 GASKET-CYLINDER HEAD | 1 | |
| 1082522 | 10 CYLINDER HEAD AS | 1 | |
| 1D4540 | 11 BOLT | 4 | |
| 7C0567 | 12 COVER-BOTTOM | 1 | |
| 9L1518 | 13 WASHER-THRUST | 2 | |
| 7C0568 | 14 GASKET-BOTTOM COVER | 1 | |
| 5M6214 | 15 PLUG-PIPE | 1 | |
| 0S1617 | 16 BOLT | 4 | |
| 7C0570 | KIT-PISTON RINGS | 1 | |
| 1070260 | KIT-MAJOR REPAIR | 1 |
