2W-5135 AIR COMPRESSOR GPS/N 90U19731-UP

Group No: 2W-5135
Part NumberPart NameQty
7H31711 PLUG-PIPE1
3J53902 PLUG (3/8-18-THD)4
2B26953 BOLT (5/16-18X0.875-IN)2
3B45054 LOCKWASHER8
9M03795 BOLT10
3J53896 PLUG (EXTERNAL)2
4W03107 CRANKSHAFT-AIR COMPRESSOR1
2H37558 BOLT (5/16-18X0.43-IN)2
2A09549 COVER-OUTLET1
1S7107GASKET1
9M039710 ADAPTER (INLET)1
8M7065GASKET (AIR INLET)1
9L227611 GUIDE-VALVE2
9L2277VALVE-INLET2
9L227812 SPRING-VALVE2
9N285513 GASKET-CYLINDER HEAD1
9N544914 CYLINDER BLOCK AS1
3H731115 GASKET-CYLINDER BLOCK1
2S401316 COVER AS-END1
2S4245BUSHING1
5M621417 PLUG (1/8-27 PTF)1
9L151718 WASHER-THRUST1
0S161719 BOLT (5/16-18X0.75-IN)4
2H393120 SEAL-O-RING1
9N544821 CRANKCASE GP-AIR COMPRESSOR1
1S986722 BUSHING1
0S159423 BOLT (3/8-16X1-IN)6
3B4506LOCKWASHER6
8N591524 PISTON AS-COMPRESSOR2
9L151825 WASHER-THRUST1
0S161526 BOLT (1/4-20X0.75-IN)6
3B4504LOCKWASHER6
4N451827 COVER-AIR COMPENSATOR1
3H5175GASKET1
8N591628 ROD AS-CONNECTING2
9M5181BOLT2
4N3994BEARING1
8S464529 LOCK4
2W513330 CYLINDER HEAD AS1
1W638831 INSERT-VALVE SPRING2
3F498732 SPRING-VALVE2
3H518133 VALVE2
9M038634 CAP2
9M038735 SEAT-VALVE SPRING2
9M039436 SEAT-VALVE2
2W6044KIT-AIR COMPRESSOR1
2W6045KIT-PISTON RING1
