System And Components
7N-8833 DRIVE GP-FANS/N 90U19731-UP
Group No: 7N-8833
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N7688 | 1 BRACKET AS-FAN | 1 | |
| 4N0684 | 1A DOWEL | 1 | |
| 1P9946 | 1B SHAFT-FAN | 1 | |
| 9N5120 | 2 BRACKET | 1 | |
| 1A2029 | 3 BOLT (3/8-16X1.125-IN) | 2 | |
| 4N2372 | 4 ADAPTER-BRACKET | 1 | |
| 8L5213 | 5 BOLT (3/8-16X4-IN) | 1 | |
| 1D4566 | 6 BOLT (1/2-13X3.5-IN) | 2 | |
| 2P9084 | 7 STUD-TAPERLOCK (1/2-13X0.83-IN, 1/2-13X0.98-IN) | 2 | |
| 7D1649 | 8 WASHER-HARD (13.5X32X5-MM THK) | 4 | |
| 1F7958 | 9 NUT-FULL (1/2-13-THD) | 2 | |
| 7N8827 | 10 HUB | 1 | |
| 5S9062 | 11 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 5S2106 | 12 SEAL-LIP TYPE | 1 | |
| 8H9789 | 13 BALL BEARING | 1 | |
| 8N5305 | 14 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 3L1425 | 15 BALL BEARING | 1 | |
| 7N2900 | 16 RETAINER | 1 | |
| 5P7979 | 17 BOLT-LOCKING (5/16-24X2.25-IN) | 2 | |
| 9F4446 | 18 SEAL-O-RING | 1 | |
| 4N2370 | 19 ADAPTER-FAN | 1 | |
| 6N0597 | 21 PULLEY-FAN DRIVE (4-GROOVE) | 1 | |
| 0L2070 | 22 BOLT (3/8-16X2.25-IN) | 6 | |
| 4N2532 | 23 V-BELT SET (INCLUDES 2-BELTS)(FAN DRIVE) | 1 | |
| 6U1989 | 24 VALVE-RELIEF (FAN DRIVE) | 1 | |
| 2D4867 | 25 FITTING-GREASE (1/8-27 PTF)(FAN DRIVE) | 1 |
