System And Components
1W4563 GEAR GP-FRONT TIMINGENGINE S/N 8Z71874-UP
Group No: 1W4563
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N2602 | 1 BOLT | 1 | |
| 7N2994 | WASHER | 1 | |
| 9N5760 | 2 WEIGHT AS (80 TEETH) | 1 | |
| 8N0498 | SEAL-FACE | 1 | |
| 6F4718 | SEAL-O-RING | 1 | |
| 1W5878 | SPRING | 2 | |
| 1W5879 | SPRING | 2 | |
| 4B1273 | SCREW-MACHINE (10-24X0.5 IN) | 2 | |
| 9N5765 | PLATE-END | 1 | |
| 9N5766 | WEIGHT | 2 | |
| 9N5767 | SLIDE | 2 | |
| 0S1594 | 3 BOLT | 2 | |
| 1064497 | 4 GEAR AS-FUEL PUMP IDLER (57 TEETH) | 1 | |
| 2S6692 | BEARING-SLEEVE | 1 | |
| 5B9079 | 5 NUT-JAM | 1 | |
| 1W4402 | 6 GEAR-CAMSHAFT (80 TEETH) | 1 | |
| 1059772 | 7 SHAFT-DRIVE IDLER | 1 | |
| 8N4960 | 8 PLATE-THRUST | 1 | |
| 0S1618 | 9 BOLT | 2 | |
| 7N4722 | 10 GEAR AS-IDLER (60 TEETH) | 1 | |
| 2P1168 | BEARING-SLEEVE | 1 | |
| 0S1748 | 11 BOLT | 4 | |
| 5M2894 | 12 WASHER | 2 |
