System And Components
1008936 AFTERCOOLER GP-WATER
Group No: 1008936
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1261689 | 1 COVER AS-AFTERCOOLER | 1 | |
| 1H5514 | 2 BOLT (5/16-18X1.625IN) | 22 | |
| 9M1974 | 3 WASHER-HARD (2MM THK) | 24 | |
| 9L5908 | 4 GASKET | 2 | |
| 7W0491 | 5 CORE AS-AFTERCOOLER | 1 | |
| 5S6735 | 6 GASKET | 2 | |
| 8T6762 | 7 PLUG-PIPE (9.52 CF SQ HOLE) | 1 | |
| 0310219 | 8 BOLT-LOCKING (3/8-16X1.75IN) | 3 | |
| 5M2894 | 9 WASHER (2.5MM THK) | 14 | |
| 1261688 | 10 HOUSING-AFTERCOOLER | 1 | |
| 9L5903 | 11 ADAPTER | 2 | |
| 6L1648 | 12 SEAL-O-RING | 2 | |
| 2W3679 | 13 GASKET | 2 | |
| 9L2625 | 14 FLANGE-TRANSFER PIPE | 1 | |
| 1N9372 | 15 GASKET-FLANGE | 1 | |
| 0343557 | 16 BOLT-LOCKING (3/8-16X1.125IN) | 4 | |
| 4N0205 | 17 SPACER (15.24MM THK) | 3 | |
| 8T6765 | 18 PLUG-PIPE (1/4-18 NPTF THD) | 1 | |
| 2B2694 | 19 BOLT (5/16-18X2IN) | 2 | |
| 1008937 | 20 BRACKET AS | 1 | |
| 1F3577 | RIVET-HEAD | 1 | |
| 0L2070 | 21 BOLT (3/8-16X2.25IN) | 1 |
