System And Components
6T3303 CONTROL GP-GOVERNOR-PART 1 OF 2POWER SHIFT
Group No: 6T3303
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2A1736 | 1 HANDLE | 1 | |
| 8G2075 | 2 LEVER (GOVERNOR CONTROL) | 1 | |
| 1B8706 | KEY-WOODRUFF | 1 | |
| 7X3181 | 3 BOLT | 1 | |
| 6V8801 | 4 NUT (3/8-16 THD) | 3 | |
| 4L9337 | 5 BOLT (3/8-16X1.50IN) | 1 | |
| 4B6493 | 6 SPRING-ROD | 1 | |
| 8T1177 | 7 BEARING-ROLLER | 2 | |
| 1L3047 | 8 WASHER | 2 | |
| 3B4629 | 9 PIN-COTTER | 1 | |
| 8F7702 | 10 SEAL-LIP (19.05MM ID) | 2 | |
| 3E4374 | 11 STUD | 2 | |
| 1093878 | 12 ROD | 1 | |
| 1A9252 | 13 END-ADJUSTMENT ROD | 2 | |
| 8D4119 | 14 LEVER | 1 | |
| 8C3121 | 15 BOLT (5/16-18X1.50IN) | 1 | |
| 6V8189 | NUT (5/16-18 THD) | 1 | |
| 3W0593 | 16 ROD | 1 | |
| 6V8183 | 17 NUT-FULL (3/8-24 THD) | 2 | |
| 4D4064 | 18 ROD END | 2 | |
| 1B0676 | 19 PIN | 2 | |
| 3B4615 | PIN-COTTER | 2 | |
| 8G3108 | 20 BELLCRANK | 1 | |
| 3W0590 | 21 BRACKET AS | 1 | |
| 5S7379 | 22 BOLT (3/8-16X.875IN) | 3 | |
| 8T4896 | WASHER-HARD (2.5MM THK) | 3 | |
| 3W4567 | 23 PEDAL | 1 | |
| 8H9186 | 24 SPRING | 2 | |
| 6Y0145 | 25 PLATE-LOCKING | 1 | |
| 8H9182 | 26 ROLLER-GOVERNOR CONTROL | 2 | |
| 5H7152 | 27 SPRING | 1 | |
| 8T0192 | 28 BOLT (3/8-16X2.25IN) | 1 | |
| 8T5353 | 29 DOWEL | 1 |
