System And Components
7C9309 CARTRIDGE GP-TURBOCHARGERPART OF 7C8632, 7E0726 TURBOCHARGERS
Group No: 7C9309
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C9699 | 1 NUT | 1 | |
| 7C9301 | 2 WHEEL-COMPRESSOR | 1 | |
| 7C9539 | 3 INSERT | 1 | |
| 5S4546 | 4 RING-RETAINING | 1 | |
| 6N1526 | 5 RING-PISTON | 1 | |
| 7C9537 | 6 BEARING | 1 | |
| 7C9536 | 7 SLEEVE | 1 | |
| 7C9531 | 8 BACKPLATE | 1 | |
| 7C9530 | 9 RING-PISTON | 1 | |
| 7C9303 | 10 WHEEL AS-TURBINE | 1 | |
| 7C9534 | 11 BEARING | 1 | |
| 7C9533 | 12 CLAMP-SPRING | 1 | |
| 7C9535 | 13 RING-THRUST | 2 | |
| 7C9540 | 14 DEFLECTOR-OIL | 1 | |
| 5P5757 | 15 SEAL-O-RING | 1 | |
| 7C9541 | 16 SLEEVE-FLINGER | 1 | |
| 7C9305 | 17 HOUSING AS | 1 | |
| 5S5199 | 18 PIN-GROOVE | 1 |
