System And Components
9Y-8898 BELT TENSIONER GPS/N 54Z486-944; 54Z946-946
Group No: 9Y-8898
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N9409 | 1 COVER | 1 | |
| 0L2070 | 2 BOLT (3/8-16X2.25-IN) | 2 | |
| 7W8460 | 3 WASHER-RETAINING | 1 | |
| 0S1617 | 4 BOLT (5/16-18X0.75-IN) | 4 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 2N8374 | 5 GASKET | 1 | |
| 8H9789 | 6 BALL BEARING | 2 | |
| 8N9419 | 7 SPACER (18.25-MM THK) | 2 | |
| 5S2106 | 8 SEAL-LIP TYPE | 1 | |
| 5M2057 | 9 SEAL-O-RING | 1 | |
| 8N9410 | 10 SPACER | 1 | |
| 8B1419 | 11 PIN-CLEVIS | 2 | |
| 3B4617 | PIN-COTTER | 2 | |
| 9Y8464 | 12 ARM AS-TIGHTENER | 1 | |
| 2D6642 | BALL (6.35MM DIA) | 1 | |
| 4S5367 | BUSHING AS (MOUNT) | 1 | |
| 5B9318 | BALL (4.76MM DIA) | 1 | |
| 5M7937 | DOWEL | 1 | |
| 9Y8458 | ARM-TIGHTENER | 1 | |
| 0S1594 | 13 BOLT (3/8-16X1-IN) | 1 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 2M2742 | 14 PLATE-RETAINER | 1 | |
| 9Y9385 | 15 PULLEY-IDLER | 1 | |
| 4B4550 | 16 FITTING-PRESSURE RELIEF (1/8-27 PTF) | 1 | |
| 8L5008 | ELBOW-PIPE | 1 | |
| 3B8686 | 17 FITTING-GREASE (1/8-27 PTF)(BELT TIGHTENER) | 1 | |
| 3V7516 | 18 HOSE AS | 1 | |
| 4D8123 | 19 CLIP (LOOP) | 1 | |
| 7N5959 | 20 SPRING | 2 | |
| 4S5882 | 21 BOLT (1/2-13X7.25-IN) | 2 | |
| 5P8245 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 0S1595 | 23 BOLT (1/2-13X1.25-IN) | 2 | |
| 9Y9410 | 24 BRACKET AS | 1 |
