System And Components
240-6652 CYLINDER BLOCK GPS/N 54Z1209-1211
Group No: 240-6652
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3501417 | 1 CYLINDER BLOCK AS | 1 | |
| 8T2929 | 3 SEAL-O-RING | 2 | |
| 1A2029 | 4 BOLT (3/8-16X1.125-IN) | 2 | |
| 7X7731 | 5 PLUG-PIPE (3/4-14-THD) | 2 | |
| 9S4191 | 6 PLUG (9/16-18-THD) | 6 | |
| 2W2940 | 7 PLUG | 8 | |
| 7N2044 | 8 DOWEL | 2 | |
| 8T6762 | 9 PLUG-PIPE (1/2-14-THD) | 4 | |
| 5M2894 | 10 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 7N2049 | 11 DOWEL | 16 | |
| 7X4805 | 12 SEAL-O-RING | 3 | |
| 1161359 | 15 BEARING-CAMSHAFT | 18 | |
| 4N0683 | 16 DOWEL | 2 | |
| 8T6763 | 17 PLUG-PIPE (1/4-18-THD) | 26 | |
| 4W4814 | 18 ADAPTER | 2 | |
| 8T0099 | 19 DOWEL | 32 | |
| 7N5641 | 20 PLUG-MANIFOLD | 2 | |
| 1977008 | 21 DOWEL | 3 | |
| 5P0840 | 22 SEAL-O-RING | 32 | |
| 1445692 | 23 GASKET-PLATE | 16 | |
| 1106994 | 24 PLATE-SPACER | 16 | |
| 5F9657 | 25 SEAL-O-RING | 4 | |
| 5P8210 | 26 SEAL-O-RING | 2 | |
| 0S1595 | 27 BOLT (1/2-13X1.25-IN) | 2 | |
| 5P8245 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8N8056 | 29 COVER | 2 | |
| 6V3348 | 30 SEAL-O-RING | 8 | |
| 8T2928 | 33 SEAL-O-RING | 2 | |
| 2147568 | 34 SEAL-O-RING | 6 | |
| 7X7731 | 35 PLUG-PIPE (3/4-14-THD) | 1 | |
| 8T6762 | 36 PLUG-PIPE (1/2-14-THD) | 2 |
