System And Components
350-5222 CYLINDER BLOCK GPS/N 54Z1212-1221
Group No: 350-5222
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W2940 | 1 PLUG (OIL MANIFOLD) | 8 | |
| 4W4814 | 2 ADAPTER | 2 | |
| 7N2047 | 3 DOWEL | 3 | |
| 7N5641 | 4 PLUG-MANIFOLD | 2 | |
| 8N8056 | 5 COVER | 2 | |
| 1161359 | 6 BEARING-CAMSHAFT | 18 | |
| 1445692 | 7 GASKET-PLATE | 16 | |
| 1977008 | 8 DOWEL | 16 | |
| 3501417 | 9 CYLINDER BLOCK AS | 1 | |
| 5197297 | 10 PLATE-SPACER | 16 | |
| 0S1595 | 11 BOLT (1/2-13X1.25-IN) | 2 | |
| 1A2029 | 12 BOLT (3/8-16X1.125-IN) | 2 | |
| 2147568 | 13 SEAL-O-RING | 6 | |
| 4N0683 | 14 DOWEL | 2 | |
| 5F9657 | 15 SEAL-O-RING | 4 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P0840 | 17 SEAL-O-RING | 32 | |
| 5P8210 | 18 SEAL-O-RING | 2 | |
| 5P8245 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V3348 | 20 SEAL-O-RING | 8 | |
| 7N2044 | 21 DOWEL | 2 | |
| 7X4805 | 22 SEAL-O-RING | 3 | |
| 7X7731 | 23 PLUG-PIPE (3/4-14-THD) | 2 | |
| 8T0099 | 24 DOWEL | 32 | |
| 8T2928 | 25 SEAL-O-RING | 2 | |
| 8T2929 | 26 SEAL-O-RING | 2 | |
| 8T6762 | 27 PLUG-PIPE (1/2-14-THD) | 4 | |
| 8T6763 | 28 PLUG-PIPE (1/4-18-THD) | 26 | |
| 9S4191 | 29 PLUG (9/16-18-THD) | 6 |
