System And Components
105-4289 HOUSING GP-FLYWHEELS/N 54Z1069-1196
Group No: 105-4289
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1067598 | 1 HOUSING AS-FLYWHEEL | 1 | |
| 3F6808 | 1A DOWEL | 1 | |
| 7N2047 | 1B DOWEL | 3 | |
| 3F6795 | 1C DOWEL | 2 | |
| 5P8245 | 2 WASHER-HARD (13.5X25.5X3-MM THK) | 19 | |
| 5R7137 | 3 WASHER-SEALING | 4 | |
| 5P4626 | 4 BOLT (5/8-11X10.5-IN) | 2 | |
| 0S1595 | 5 BOLT (1/2-13X1.25-IN) | 7 | |
| 8T6765 | 6 PLUG-PIPE (1/4-18-THD) | 1 | |
| 8T6763 | 7 PLUG-PIPE (1/4-18-THD) | 5 | |
| 1D4574 | 8 BOLT (1/2-13X6-IN) | 8 | |
| 5D9514 | 9 BOLT (5/8-11X6.25-IN) | 12 | |
| 1D4597 | 10 BOLT (5/8-11X6.5-IN) | 1 | |
| 5P8247 | 11 WASHER-HARD (17X32X3.5-MM THK) | 17 | |
| 8M5255 | 12 SEAL-O-RING | 1 | |
| 4P5218 | 13 COVER | 1 | |
| 9X8873 | 14 BOLT (1/2-13X2.25-IN) | 2 | |
| 5D3954 | 15 STUD-TAPERLOCK (5/8-11X4.4-IN) | 2 | |
| 4K0367 | 16 NUT-FULL (5/8-11-THD) | 2 | |
| 1V6341 | 17 SEAL | 2 | |
| 4P5217 | 18 COVER | 1 | |
| 1A1460 | 19 BOLT (1/2-13X2-IN) | 2 | |
| 1044767 | 20 ADAPTER | 1 | |
| 9S4185 | 21 PLUG (3/4-16-THD) | 1 | |
| 3K0360 | 22 SEAL-O-RING | 1 | |
| 4B8407 | 23 GASKET-COPPER | 1 | |
| 1A1460 | 24 BOLT (1/2-13X2-IN) | 2 | |
| 9X8873 | 25 BOLT (1/2-13X2.25-IN) | 2 |
