4P-5219 HOUSING GP-FLYWHEELS/N 54Z747-1068

Group No: 4P-5219
Part NumberPart NameQty
7E90871 HOUSING AS-FLYWHEEL1
3F68082 DOWEL1
7N20473 DOWEL3
3F67954 DOWEL2
1A14605 BOLT (1/2-13X2-IN)2
5P46266 BOLT (5/8-11X10.5-IN)2
0S15957 BOLT (1/2-13X1.25-IN)7
0S15878 BOLT (1/2-13X1.75-IN)2
8T67639 PLUG-PIPE (1/4-18-THD)6
1D457410 BOLT (1/2-13X6-IN)7
5D951411 BOLT (5/8-11X6.25-IN)12
1D459712 BOLT (5/8-11X6.5-IN)1
5P824713 WASHER-HARD (17X32X3.5-MM THK)17
5P824514 WASHER-HARD (13.5X25.5X3-MM THK)17
9S418515 PLUG (3/4-16-THD)1
3K036016 SEAL-O-RING1
8M525517 SEAL-O-RING1
4P521818 COVER1
2B094719 BOLT (1/2-13X2.25-IN)2
5D395420 STUD-TAPERLOCK (5/8-11X4.4-IN)2
4K036721 NUT-FULL (5/8-11-THD)2
1V634122 SEAL2
4P521723 COVER1
