System And Components
7E-9413 LINES GP-TURBOCHARGER OILS/N 54Z871-871; 54Z873-873; 54Z878-1208
Group No: 7E-9413
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N5094 | 1 ELBOW-DRAIN | 4 | |
| 5P9890 | 2 SEAL-O-RING | 8 | |
| 9L9132 | 3 WASHER-HARD (10.2X25.5X2.5-MM THK) | 8 | |
| 7E5335 | 4 BRACKET | 4 | |
| 6K5535 | 5 CLIP (SLOT) | 4 | |
| 6K5536 | 6 CLIP (TAB) | 4 | |
| 0S1594 | 7 BOLT (3/8-16X1-IN) | 4 | |
| 2789544 | 8 TUBE (RH) | 2 | |
| 9S8752 | 9 NUT-FULL (3/8-16-THD) | 16 | |
| 9Y5814 | 10 ELBOW-DRAIN | 4 | |
| 7N7559 | 11 GASKET | 4 | |
| 0T0055 | 12 BOLT (3/8-16X4.25-IN) | 8 | |
| 5M2894 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 20 | |
| 2789542 | 14 TUBE (LH) | 2 | |
| 0S1588 | 15 BOLT (3/8-16X1.25-IN) | 16 | |
| 2W0752 | 16 GASKET | 4 | |
| 3535133 | 17 ELBOW AS | 1 | |
| 0307949 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 6V4589 | 18 SEAL-O-RING | 1 | |
| 4P0692 | 19 CLAMP AS | 24 | |
| 1081434 | GROMMET | 1 | |
| 0038581 | 20 TEE-UNION | 2 | |
| 9M4584 | 21 CONNECTOR | 1 | |
| 7E0949 | 22 TUBE AS | 1 | |
| 7E0950 | 23 TUBE AS | 1 | |
| 0T0573 | 24 BOLT (3/8-16X2.75-IN) | 12 | |
| 3B1915 | 25 BOLT (3/8-16X1.375-IN) | 4 | |
| 0S1608 | 26 BOLT (3/8-16X3.75-IN) | 4 | |
| 1843230 | 27 HOSE AS | 4 | |
| 6I0812 | 28 TUBE AS-OIL | 2 | |
| 4P4460 | 29 GASKET | 4 | |
| 6I0805 | 30 ADAPTER-TURBOCHARGER OIL | 2 | |
| 6I0804 | 31 ADAPTER-TURBOCHARGER OIL | 2 | |
| 8L2786 | 32 SEAL-O-RING | 4 | |
| 2P7636 | 33 CONNECTOR (3/4-16 STR-THD) | 4 | |
| 2501496 | 34 ELBOW | 2 | |
| 1274469 | 35 BRACKET | 2 | |
| 8M9024 | 36 WASHER-HARD (10.2X22.5X5-MM THK) | 12 |
