System And Components
7E-6731 AFTERCOOLER GP-AIRS/N 54Z486-844
Group No: 7E-6731
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W5728 | 1 SLEEVE | 2 | |
| 3J5390 | 2 PLUG (3/8-18-THD) | 1 | |
| 7W0228 | 3 CONNECTOR | 2 | |
| 7W0227 | PLUG | 2 | |
| 4W3108 | VALVE AS | 2 | |
| 2B0858 | 4 PLUG-PIPE | 4 | |
| 1T0720 | 5 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 28 | |
| 5M2894 | 6 WASHER-HARD (10.2X18.5X2.5-MM THK) | 88 | |
| 0L1143 | 7 BOLT (3/8-16X2.5-IN) | 60 | |
| 1W4955 | 8 SPACER (11.36X17.46X27-MM THK) | 60 | |
| 1W1253 | 9 GASKET | 3 | |
| 4P1569 | 10 GASKET | 1 | |
| 8N2409 | 11 ADAPTER | 2 | |
| 7M9909 | 12 SEAL-O-RING | 2 | |
| 6V1454 | 13 SEAL-O-RING | 11 | |
| 1W1258 | 14 HOUSING-FRONT | 1 | |
| 1W1259 | 15 HOUSING-INTERMEDIATE | 2 | |
| 8N1237 | 16 PIPE | 1 | |
| 0S1594 | 17 BOLT (3/8-16X1-IN) | 6 | |
| 8N1238 | 18 PIPE | 1 | |
| 1W1260 | 19 HOUSING-REAR | 1 | |
| 1A9066 | 20 GASKET | 1 | |
| 0314630 | 21 BOLT-LOCKING (5/16-18X0.75-IN) | 30 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 30 | |
| 4N0684 | 22 DOWEL | 6 | |
| 7W5456 | 23 CORE AS-AFTERCOOLER | 2 | |
| 8N1239 | 24 COVER | 1 | |
| 1M7913 | 25 RING-RETAINING | 2 | |
| 5M7423 | 26 SEAL-O-RING | 2 | |
| 2W6171 | 27 ADAPTER | 1 |
