System And Components
8X-0062 LINES GP-PILOTS/N 9YF140-159
Group No: 8X-0062
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8C3205 | 1 FLANGE-HALF | 4 | |
| 4J5267 | SEAL-O-RING | 2 | |
| 8T4196 | 2 BOLT (M10X1.5X35-MM) | 8 | |
| 8T4121 | 3 WASHER-HARD (11X21X2.5-MM THK) | 21 | |
| 1235166 | 4 HOSE AS | 1 | |
| 8X1547 | 5 TUBE AS | 1 | |
| 6V9843 | 6 TEE | 6 | |
| 6V8397 | 7 SEAL-O-RING | 57 | |
| 1209532 | 8 TUBE AS | 1 | |
| 1197275 | 9 TUBE AS | 1 | |
| 3J1907 | 10 SEAL-O-RING | 20 | |
| 6V8636 | 11 CONNECTOR | 11 | |
| 6V8635 | 12 CONNECTOR | 3 | |
| 7M8485 | 13 SEAL-O-RING | 3 | |
| 5K9090 | 14 SEAL-O-RING | 5 | |
| 6V8998 | 15 UNION | 1 | |
| 9W8826 | 16 HOSE AS | 1 | |
| 1197276 | 17 BLOCK | 1 | |
| 8T4136 | 18 BOLT (M10X1.5X25-MM) | 2 | |
| 8T5005 | 19 BOLT (M10X1.5X70-MM) | 5 | |
| 6V9172 | 20 NUT (1-7/16-12-THD) | 1 | |
| 6V8398 | 21 SEAL-O-RING | 7 | |
| 6V8994 | 22 UNION (STRAIGHT) | 5 | |
| 6V9168 | NUT (11/16-16-THD) | 5 | |
| 6V8995 | 23 UNION (STRAIGHT) | 1 | |
| 6V9169 | NUT (13/16-16-THD) | 1 | |
| 6V9851 | 24 ELBOW | 2 | |
| 8T4178 | 25 BOLT (M10X1.5X90-MM) | 3 | |
| 8T4133 | 26 NUT (M10X1.5-THD) | 8 | |
| 6V9844 | 27 TEE-SWIVEL | 1 | |
| 6V8936 | 28 REDUCER | 1 | |
| 6V9850 | 29 ELBOW (90 DEGREE) | 11 | |
| 1209529 | 30 TUBE AS | 1 | |
| 9T7200 | 31 MANIFOLD | 1 | |
| 6V9507 | 32 PLUG | 1 | |
| 1195988 | 33 VALVE GP-SELECTOR & PRESS CONT | 1 | |
| 9T3096 | 34 VALVE GP-CHECK | 1 | |
| 6V8724 | 35 ELBOW | 4 | |
| 8X1544 | 36 TUBE AS | 4 | |
| 6V9872 | 37 CONNECTOR | 1 | |
| 3J7354 | 38 SEAL-O-RING | 2 | |
| 8X1549 | 39 TUBE AS | 1 | |
| 8C3446 | 40 VALVE-SAMPLING | 1 | |
| 9T6005 | 41 VALVE GP-CHECK | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 8X1542 | 42 TUBE AS | 1 | |
| 1180018 | 43 VALVE GP-RELIEF | 1 | |
| 8X8810 | 44 TUBE AS | 4 | |
| 8X0744 | 45 TUBE AS | 1 | |
| 8X1535 | 46 PLATE | 1 | |
| 8X8809 | 47 HOSE AS | 1 | |
| 6V0852 | 48 CAP-DUST | 1 | |
| 1184544 | 49 HOSE AS | 1 | |
| 4J0522 | 50 SEAL-O-RING | 2 | |
| 6V0397 | 51 FLANGE-HALF | 4 | |
| 8T4183 | 52 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4223 | 53 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 2M9780 | 54 SEAL-O-RING | 3 | |
| 5P1404 | 55 ADAPTER | 1 | |
| 6V8715 | 56 CONNECTOR | 1 | |
| 6V8774 | 57 TEE | 1 | |
| 6V8781 | 58 TEE | 1 | |
| 6V9001 | 59 ELBOW | 1 | |
| 8J2602 | 60 VALVE GP-SELECTOR | 1 | |
| 9S4190 | 61 PLUG-O-RING (7/8-14-THD) | 1 | |
| 1209528 | 62 TUBE AS | 1 | |
| 1209530 | 63 TUBE AS | 1 | |
| 1209531 | 64 TUBE AS | 1 |
