System And Components
350-5218 CYLINDER BLOCK GPS/N 7YG2253-2256; C8X107-129
Group No: 350-5218
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1595 | 1 BOLT (1/2-13X1.25-IN) | 2 | |
| 1A2029 | 2 BOLT (3/8-16X1.125-IN) | 2 | |
| 2W2940 | 3 PLUG (OIL MANIFOLD)(OIL MANIFOLD) | 8 | |
| 4N0683 | 4 DOWEL | 2 | |
| 4W4814 | 5 ADAPTER | 1 | |
| 5M2894 | 6 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P0840 | 7 SEAL-O-RING | 16 | |
| 5P8210 | 8 SEAL-O-RING | 2 | |
| 5P8245 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 7N2044 | 10 DOWEL | 2 | |
| 7N2047 | 11 DOWEL | 3 | |
| 7N5641 | 12 PLUG-MANIFOLD | 2 | |
| 7X4805 | 13 SEAL-O-RING | 3 | |
| 7X7731 | 14 PLUG-PIPE (3/4-14-THD) | 2 | |
| 8N8056 | 15 COVER | 2 | |
| 8T0099 | 16 DOWEL | 16 | |
| 8T2928 | 17 SEAL-O-RING | 1 | |
| 8T2929 | 18 SEAL-O-RING | 1 | |
| 8T6762 | 19 PLUG-PIPE (1/2-14-THD) | 3 | |
| 8T6763 | 20 PLUG-PIPE (1/4-18-THD) | 18 | |
| 9S4191 | 21 PLUG (9/16-18-THD) | 6 | |
| 1161359 | 22 BEARING-CAMSHAFT | 10 | |
| 1977008 | 23 DOWEL | 8 | |
| 2147568 | 24 SEAL-O-RING | 6 | |
| 1445692 | 25 GASKET-PLATE | 8 | |
| 3501409 | 26 CYLINDER BLOCK GP | 1 | |
| 5197297 | 27 PLATE-SPACER | 8 | |
| 5F9657 | 28 SEAL-O-RING | 4 | |
| 6V3348 | 29 SEAL-O-RING | 8 |
