System And Components
1W-8704 DRIVE GP-AUXILIARY -LOWER, LHS/N 7YG1-1044
Group No: 1W-8704
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W0548 | 1 GEAR AS (47/60 TEETH) | 1 | |
| 8N5301 | BEARING | 1 | |
| 7C3261 | 2 SHAFT | 1 | |
| 8M5255 | 3 SEAL-O-RING | 2 | |
| 2W0552 | 4 GEAR-WATER PUMP DRIVE (65-TEETH) | 1 | |
| 2W0553 | 5 SHAFT | 1 | |
| 6K3771 | 6 BOLT-12 POINT HEAD (7/16-14X1.5-IN) | 12 | |
| 7N7539 | 7 WASHER-THRUST | 2 | |
| 2B2695 | 8 BOLT (5/16-18X0.875-IN) | 4 | |
| 9M1974 | 9 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 2W0554 | 10 ADAPTER AS | 1 | |
| 2M4453 | 11 SEAL-O-RING | 1 | |
| 4D0514 | 12 PLUG-PIPE | 1 | |
| 0T0055 | 13 BOLT (3/8-16X4.25-IN) | 1 | |
| 1D4572 | 14 BOLT (1/2-13X5.5-IN) | 2 | |
| 1T0720 | 15 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 2 | |
| 4S6137 | 16 STUD-TAPERLOCK (3/8-16X3.1-IN) | 4 | |
| 7C3258 | 17 WASHER AS-THRUST | 1 | |
| 7N2047 | DOWEL | 1 | |
| 5P8245 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 5R7137 | WASHER-SEALING | 2 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5R7136 | WASHER-SEALING | 1 |
