System And Components
8N-9793 DRIVE GP-FANS/N 7YG1-1407
Group No: 8N-9793
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W0422 | 1 V-BELT SET (INCLUDES 4-BELTS)(FAN DRIVE) | 1 | |
| 1W0424 | 2 BRACKET AS-FAN | 1 | |
| 2W1660 | 3 ADAPTER-FAN | 1 | |
| 3B8686 | 4 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 3G0570 | 5 HOSE AS (LUBRICATION) | 1 | |
| 7K8790 | 6 SPACER (0.53X1.1X0.44-MM THK) | 2 | |
| 7N7660 | 7 DRIVE GP-FAN | 1 | |
| 8N9764 | 8 HUB-FAN PULLEY | 1 | |
| 8N9765 | 9 SPACER (52X70X66-MM THK) | 1 | |
| 8N9766 | 10 SPACER | 1 | |
| 8N9768 | 11 WASHER-RETAINING (20.5X75X25-MM THK) | 1 | |
| 9Y5010 | 12 ADAPTER-GREASE | 1 | |
| 2297306 | 13 PULLEY AS-CRANKSHAFT (6-GROOVE) | 1 | |
| 3543021 | 14 BRACKET AS | 1 | |
| 0S0509 | 15 BOLT (3/8-16X0.75-IN) | 2 | |
| 1653931 | 16 BOLT (3/8-16X1.75-IN) | 6 | |
| 1A2029 | 17 BOLT (3/8-16X1.125-IN) | 1 | |
| 1D4597 | 18 BOLT (5/8-11X6.5-IN) | 2 | |
| 1D4624 | 19 BOLT (3/4-10X9-IN) | 1 | |
| 1N4036 | 20 PULLEY-FAN DRIVE | 1 | |
| 1T0210 | 21 BALL BEARING | 2 | |
| 2A4639 | 22 BOLT (3/8-16X1.625-IN) | 2 | |
| 3B1915 | 23 BOLT (3/8-16X1.375-IN) | 6 | |
| 3H0120 | 24 ELBOW | 1 | |
| 6U1989 | 25 VALVE-RELIEF | 1 | |
| 4D8123 | 26 CLIP (LOOP) | 3 | |
| 5F3144 | 27 SEAL-O-RING | 1 | |
| 5K5959 | 28 SEAL-O-RING | 1 | |
| 5M2894 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 5P5299 | 30 SEAL-LIP TYPE | 1 | |
| 5P8245 | 31 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6F5282 | 32 BOLT (1/2-13X5.25-IN) | 2 | |
| 7X7730 | 33 PLUG-PIPE | 1 | |
| 8S3887 | 34 BOLT (1/2-13X11-IN) | 2 | |
| 9H8260 | 35 BOLT (1/2-13X6.25-IN) | 2 | |
| 9L9132 | 36 WASHER-HARD (10.2X25.5X2.5-MM THK) | 1 | |
| 9S8752 | 37 NUT-FULL (3/8-16-THD) | 1 | |
| 4W0335 | KIT-BUSHING (CRANKSHAFT PULLEY) | 1 |
