Assembly
100%

112-5677 GEAR GP-REAR -CAM DRIVES/N 7YG961-UP; C8X1-UP

Group No: 112-5677
Part NumberPart NameQty
2W28951 GEAR-CRANKSHAFT (92-TEETH)1
3S13072 BOLT-12 POINT HEAD (3/8-16X2-IN)12
4P54593 GEAR AS-BALANCER (136-TEETH)(CLUSTER IDLER-REAR)1
4P54383A BUSHING1
4P54374 SHAFT-GEAR (CLUSTER)1
8M25305 BOLT-12 POINT HEAD (1/2-13X1.25-IN)4
10113656 PLATE-THRUST1
0L13517 BOLT (3/8-16X0.875-IN)4
11215548 GEAR AS-IDLER (88-TEETH)2
12597518A BUSHING1
11215529 SHAFT-IDLER2
9X888710 BOLT (3/4-10X3-IN)2
5P824811 WASHER-HARD (20X36.5X3.5-MM THK)2
1B436712 BOLT (5/8-11X3-IN)4
101136813 WASHER-THRUST (19.5X106X1.9-MM THK)2
7E389714 GEAR-CAMSHAFT DRIVE (88-TEETH)2
4W458615 PLATE1
7E532416 RING1
8S233117 BOLT-12 POINT HEAD (5/8-11X2-IN)2
