Assembly
100%

109-8081 LINES GP-TURBOCHARGER OILS/N 7YG776-UP; C8X1-UP

Group No: 109-8081
Part NumberPart NameQty
2W07521 GASKET2
4P06922 CLAMP AS4
1081434GROMMET2
6I08043 ADAPTER-TURBOCHARGER OIL1
6I08054 ADAPTER-TURBOCHARGER OIL1
6I08105 TUBE AS-OIL1
7E53356 BRACKET2
7N50947 ELBOW-DRAIN2
7N75598 GASKET2
9Y00479 CLAMP8
9Y581410 ELBOW-DRAIN2
184322911 HOSE AS2
235026312 TUBE AS1
278954213 TUBE (LH)1
278954414 TUBE (RH)(RH)1
031413615 TEE-FLARED1
100323716 GROMMET8
0L207017 BOLT (3/8-16X2.25-IN)2
0S158818 BOLT (3/8-16X1.25-IN)8
0S159419 BOLT (3/8-16X1-IN)2
0S160820 BOLT (3/8-16X3.75-IN)2
0T005521 BOLT (3/8-16X4.25-IN)2
2B269422 BOLT (5/16-18X2-IN)4
2P763623 CONNECTOR (3/4-16 STR-THD)2
3B191524 BOLT (3/8-16X1.375-IN)2
5M289425 WASHER-HARD (10.2X18.5X2.5-MM THK)6
250149626 ELBOW2
5P989027 SEAL-O-RING4
6K553528 CLIP (SLOT)2
6K553629 CLIP (TAB)2
6V458930 SEAL-O-RING1
8L278631 SEAL-O-RING2
8S919132 BOLT (3/8-16X4-IN)2
9L913233 WASHER-HARD (10.2X25.5X2.5-MM THK)4
9N086934 WASHER-HARD (8.8X25.5X2-MM THK)4
9S875235 NUT-FULL (3/8-16-THD)2
4P446036 GASKET2
