7E-5541 LINES GP-TURBOCHARGER OILS/N 7YG1-775

Group No: 7E-5541
Part NumberPart NameQty
7N50941 ELBOW-DRAIN2
5P98902 SEAL-O-RING4
7E53383 TUBE1
7E53354 BRACKET2
6K55355 CLIP (SLOT)2
6K5536CLIP (TAB)2
0S16086 BOLT (3/8-16X3.75-IN)2
0S15947 BOLT (3/8-16X1-IN)2
9S8752NUT-FULL (3/8-16-THD)2
9L9132WASHER-HARD (10.2X25.5X2.5-MM THK)4
4P44608 GASKET2
3B19159 BOLT (3/8-16X1.375-IN)2
9Y581410 ELBOW-DRAIN2
7N755911 GASKET2
7E554312 TUBE AS-SUPPLY1
0T005513 BOLT (3/8-16X4.25-IN)4
5M289414 WASHER-HARD (10.2X18.5X2.5-MM THK)6
9R500815 SPACER (11X20X6-MM THK)2
7E534016 TUBE AS-SUPPLY1
1W799017 TUBE1
0S158818 BOLT (3/8-16X1.25-IN)8
2W075219 GASKET2
031413620 TEE-FLARED1
6V458921 SEAL-O-RING1
4P069222 CLAMP AS4
0L207023 BOLT (3/8-16X2.25-IN)2
4P069324 CLAMP AS8
9Y0047CLAMP1
1081434GROMMET2
2B269425 BOLT (5/16-18X2-IN)4
9N0869WASHER-HARD (8.8X25.5X2-MM THK)4
4P693226 SHIELD2
