System And Components
2W-0731 AFTERCOOLER GP-TREATED WATERS/N 7YG319-UP; C8X1-UP
Group No: 2W-0731
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W5456 | 1 CORE AS-AFTERCOOLER | 1 | |
| 0314630 | 2 BOLT-LOCKING (5/16-18X0.75-IN) | 14 | |
| 8M9024 | 3 WASHER-HARD (10.2X22.5X5-MM THK) | 28 | |
| 6V1454 | 4 SEAL-O-RING | 6 | |
| 1M7913 | 5 RING-RETAINING | 1 | |
| 5M7423 | 6 SEAL-O-RING | 4 | |
| 1078758 | 7 HOUSING-FRONT | 1 | |
| 2W1382 | 8 ELBOW | 1 | |
| 1078760 | 9 HOUSING-REAR | 1 | |
| 1W1253 | 10 GASKET | 1 | |
| 4N0684 | 11 DOWEL | 2 | |
| 1T0720 | 12 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 12 | |
| 5M2894 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 1008058 | 14 GASKET | 1 | |
| 0T0065 | 15 BOLT (3/8-16X3.5-IN) | 28 | |
| 5F4899 | 16 BOLT (3/8-16X5.5-IN) | 2 | |
| 8N2409 | 17 ADAPTER | 2 | |
| 7M9909 | 18 SEAL-O-RING | 2 | |
| 1W5728 | 19 SLEEVE | 2 | |
| 8T6762 | 20 PLUG-PIPE (1/2-14-THD) | 4 | |
| 2301072 | 21 GASKET | 1 | |
| 6I4459 | 22 SPACER (51-MM THK) | 28 | |
| 7W0229 | 23 CONNECTOR AS | 1 | |
| 7W0227 | PLUG | 1 | |
| 4W3108 | VALVE AS | 1 | |
| 8T6767 | 24 PLUG-PIPE (3/8-18-THD) | 2 |
