System And Components
9Y-8267 CARTRIDGE GP-TURBOCHARGERS/N 7YG1-UP; C8X1-UP
Group No: 9Y-8267
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N7962 | 1 PLATE AS-BACKING | 1 | |
| 7W0130 | BEARING-THRUST | 1 | |
| 7W0131 | STUD-DRIVE | 3 | |
| 1P1120 | 2 RING-SEAL | 1 | |
| 6N5004 | 3 BEARING-THRUST | 1 | |
| 7N3759 | 4 RING-PISTON | 1 | |
| 0S1616 | 5 BOLT (1/4-20X1-IN) | 4 | |
| 9N2036 | PLATE-LOCK | 4 | |
| 9Y8268 | 6 SHAFT AS | 1 | |
| 9M8915 | 7 RING-RETAINING | 3 | |
| 7E9493 | 8 HOUSING AS-BEARING | 1 | |
| 4M6646 | PIN-GROOVED | 2 | |
| 7W2368 | RING-SEAL | 1 | |
| 9M8911 | 9 COLLAR-THRUST | 1 | |
| 9N2046 | 10 SPACER-THRUST | 1 | |
| 9M8919 | RING-SEAL | 2 | |
| 1S1770 | 11 LOCKNUT-TURBOCHARGER | 1 | |
| 4P3429 | 12 WHEEL-COMPRESSOR | 1 | |
| 9N2041 | 13 KIT-BEARING | 1 | |
| 7N3193 | KIT-BEARING (0.13-MM OS,0.13-MM US)(TURBO CARTRIDGE) | 1 | |
| 7N3194 | KIT-BEARING (0.25-MM OS, 0.25-MM US)(TURBO CARTRIDGE) | 1 | |
| 8N4157 | KIT-BEARING (0.25-MM OS)(TURBO CARTRIDGE) | 1 | |
| 8N4158 | KIT-BEARING (0.13-MM OS)(TURBO CARTRIDGE) | 1 | |
| 8N4159 | KIT-BEARING (0.13-MM US)(TURBO CARTRIDGE) | 1 | |
| 8N4160 | KIT-BEARING (0.25-MM US)(TURBO CARTRIDGE) | 1 | |
| 7C7446 | KIT-BEARING (0.51-MM OS)(TURBO CARTRIDGE) | 1 | |
| 7C7447 | KIT-BEARING (0.51-MM OS, 0.25-MM US)(TURBO CARTRIDGE) | 1 |
