System And Components
7C-4013 MUFFLER GPS/N 4XJ1-UP; 2TK1-79
Group No: 7C-4013
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1114352 | 1 MUFFLER AS | 1 | |
| 8W4259 | 2 STRAP AS | 2 | |
| 8T2501 | 3 BOLT (3/8-16X2-IN) | 8 | |
| 6V8801 | NUT (3/8-16-THD) | 8 | |
| 8T4896 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 20 | |
| 8W4261 | 5 STRAP AS | 2 | |
| 8W4264 | 6 BRACE | 1 | |
| 8T8917 | 7 BOLT (1/2-13X1.25-IN) | 3 | |
| 8T4223 | 8 WASHER-HARD (13.5X25.5X3-MM THK) | 9 | |
| 6V8188 | 9 NUT (1/2-13-THD) | 5 | |
| 5P2228 | 10 BOLT (1/2-13X1-IN) | 1 | |
| 8T4835 | 11 BOLT (1/2-13X2-IN) | 1 | |
| 6N9298 | 12 CLAMP | 1 | |
| 1W3394 | 13 EXTENSION-EXHAUST | 1 | |
| 4N9330 | 14 CLAMP | 1 | |
| 5P2424 | 15 BOLT (1/2-13X2.25-IN) | 1 | |
| 1102756 | 16 BRACKET AS | 1 | |
| 5S7379 | 17 BOLT (3/8-16X0.875-IN) | 4 |
