System And Components
7C-4013 MUFFLER GPS/N 4XJ1-UP; 2TK80-UP
Group No: 7C-4013
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8W4260 | 1 STRAP | 2 | |
| 8W4261 | 2 STRAP AS | 2 | |
| 1114352 | 3 MUFFLER AS | 1 | |
| 1299477 | 4 EXTENSION-EXHAUST | 1 | |
| 1864178 | 5 BRACKET AS | 1 | |
| 3445675 | 6 NUT (M10X1.5-THD) | 10 | |
| 4N9330 | 7 CLAMP | 1 | |
| 6C3241 | 8 BOLT (1/2-13X1.5-IN) | 2 | |
| 6N9298 | 9 CLAMP | 1 | |
| 6V8188 | 10 NUT (1/2-13-THD) | 2 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 24 | |
| 8T4185 | 12 BOLT (M10X1.5X50-MM) | 9 | |
| 8T4223 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T6466 | 14 BOLT (M10X1.5X60-MM) | 1 | |
| 9B7237 | 15 BOLT (3/8-16X1.25-IN) | 4 |
