System And Components
114-0935 LINES GP-SERVICE BRAKE -REARS/N 4XJ977-UP; 2TK94-UP
Group No: 114-0935
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V8636 | 1 CONNECTOR | 1 | |
| 3J1907 | 2 SEAL-O-RING | 7 | |
| 1131543 | 3 VALVE GP-BRAKE (PARKING, SECONDARY) | 1 | |
| 8T8901 | 4 TEE-O-RING PORT | 1 | |
| 3D2824 | 5 SEAL-O-RING | 10 | |
| 6V9746 | 6 SEAL-O-RING | 10 | |
| 6V8397 | 7 SEAL-O-RING | 11 | |
| 6V9007 | 8 ELBOW | 3 | |
| 8X6603 | 9 HOSE AS | 1 | |
| 6V8724 | 10 ELBOW | 1 | |
| 1102225 | 11 TANK GP-AIR (SERVICE BRAKE) | 1 | |
| 8W3405 | 12 CYLINDER GP-AIR/HYDRAULIC (REAR OIL COOLED) | 1 | |
| 8W4516 | 13 HOSE AS | 1 | |
| 3K0360 | 14 SEAL-O-RING | 11 | |
| 6V8625 | 15 ELBOW | 2 | |
| 1P3707 | 16 SEAL-RECTANGULAR | 1 | |
| 6V8398 | 17 SEAL-O-RING | 10 | |
| 1125738 | 18 HOSE AS | 1 | |
| 7X3192 | 19 BOLT (5/8-18X2-IN) | 3 | |
| 8T4122 | 20 WASHER-HARD (17X32X3.5-MM THK) | 5 | |
| 6V3965 | 21 FITTING (QUICK DISCONNECT) | 2 | |
| 6V0852 | 22 CAP-DUST | 2 | |
| 6V8629 | 23 ELBOW | 1 | |
| 2M9780 | 24 SEAL-O-RING | 8 | |
| 6V8774 | 25 TEE | 1 | |
| 6V9004 | 27 ELBOW | 1 | |
| 7M8485 | 28 SEAL-O-RING | 1 | |
| 5P5777 | 29 ADAPTER-O-RING | 1 | |
| 8X1872 | 30 HOSE AS | 1 | |
| 6G1444 | 31 ADAPTER | 1 | |
| 8T9391 | 32 BOLT (1/2-13X3.75-IN) | 8 | |
| 5T9986 | 33 HOSE AS | 1 | |
| 4J0522 | 34 SEAL-O-RING | 2 | |
| 8T5360 | 35 WASHER (12X22.5X2.5-MM THK) | 8 | |
| 7X0308 | 36 BOLT (7/16-14X1.375-IN) | 8 | |
| 1P4578 | 37 FLANGE-HALF | 4 | |
| 3J7354 | 38 SEAL-O-RING | 1 | |
| 4L6454 | 39 BOLT (3/8-16X1-IN) | 2 | |
| 1170138 | 40 HOSE AS | 1 | |
| 8X1871 | 41 HOSE AS | 1 | |
| 5T9701 | 42 HOSE AS | 1 | |
| 4D5371 | 43 CLIP | 4 | |
| 6V9872 | 44 CONNECTOR | 1 | |
| 6V9836 | 45 TEE-SWIVEL | 1 | |
| 3G2887 | 46 VALVE GP-DIVERTER (TOWING/PARKING BRAKE RELEASE) | 1 | |
| 1P4576 | 47 FLANGE-HALF | 2 | |
| 9B7237 | 48 BOLT (3/8-16X1.25-IN) | 4 | |
| 8T4896 | 49 WASHER-HARD (10.2X18.5X2.5-MM THK) | 23 | |
| 4J5267 | 50 SEAL-O-RING | 1 | |
| 1S0994 | 51 CLIP (LOOP) | 2 | |
| 8Y7414 | 52 HOSE AS | 1 | |
| 8T4223 | 53 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 9D6937 | 54 BRACKET | 1 | |
| 5C6565 | 55 BOLT (1/2-13X1.125-IN) | 4 | |
| 8T2501 | 56 BOLT (3/8-16X2-IN) | 2 | |
| 6P4603 | 57 FILTER GP-OIL | 1 | |
| 8T2502 | 58 BOLT (3/8-16X1.125-IN) | 3 | |
| 6V8775 | 59 TEE-FACE SEAL | 1 | |
| 8T8919 | 60 BOLT (1/2-13X1.75-IN) | 1 | |
| 7X0345 | 61 BOLT (5/8-11X1.75-IN) | 2 | |
| 7X0448 | 62 NUT (5/8-11-THD) | 2 | |
| 9S4191 | 63 PLUG (9/16-18-THD) | 1 | |
| 8W9915 | 64 PLATE | 1 | |
| 8T5429 | 65 ELBOW | 2 | |
| 8T6876 | 66 ELBOW | 1 | |
| 8J5604 | 67 BREATHER AS | 1 | |
| 5T5973 | 68 PLATE | 1 | |
| 7J9108 | 69 SEAL-O-RING | 8 | |
| 8X1860 | 71 TUBE AS | 1 | |
| 6V9003 | 72 ELBOW | 2 | |
| 4S4455 | 73 CLIP | 5 | |
| 8W0340 | 74 HOSE AS | 1 | |
| 6V8721 | 75 ELBOW | 1 | |
| 8X1859 | 76 TUBE AS | 1 | |
| 6V8626 | 77 ELBOW | 2 | |
| 5T7484 | 78 JUNCTION BLOCK | 2 | |
| 4L6459 | 79 BOLT (3/8-16X2.5-IN) | 4 | |
| 8C4436 | 80 BOLT (1/2-13X1.375-IN) | 1 | |
| 8J8197 | 81 CLIP | 2 | |
| 2G5900 | 82 SLACK ADJUSTER GP (REAR) | 1 | |
| 6V8642 | 83 CONNECTOR | 2 | |
| 6V9002 | 84 ELBOW | 3 | |
| 8W6812 | 85 HOSE AS | 1 | |
| 8X1862 | 86 TUBE AS | 1 | |
| 9M8406 | 87 CLIP (LOOP) | 4 | |
| 9S4183 | 88 PLUG (1-1/16-12-THD) | 1 | |
| 8X1861 | 89 TUBE AS | 1 | |
| 8X1873 | 90 HOSE AS | 1 | |
| 5M3062 | 91 BOLT (3/8-16X0.75-IN) | 7 | |
| 3D0471 | 92 STUD-TAPERLOCK (1/2-13-THD) | 1 | |
| 5P7466 | 93 CLIP (SLOT) | 4 | |
| 5P7467 | 94 CLIP (TAB) | 4 | |
| 5P8112 | 95 GROMMET | 4 | |
| 3B9818 | 96 SPACER (1.375-IN THK) | 1 | |
| 6V8188 | 97 NUT (1/2-13-THD) | 1 | |
| 5P2228 | 98 BOLT (1/2-13X1-IN) | 1 | |
| 6V8637 | 99 CONNECTOR | 1 | |
| 6V9853 | 100 ELBOW | 1 | |
| 4M2743 | 101 STUD-TAPERLOCK (3/8-16-THD) | 1 | |
| 6V8801 | 102 NUT (3/8-16-THD) | 1 | |
| 8X9937 | 103 HOSE AS | 1 | |
| 6V8632 | 104 CONNECTOR | 2 | |
| 6V8723 | 105 ELBOW | 1 | |
| 6V9876 | 106 ELBOW | 2 | |
| 6V9846 | 107 TEE | 1 | |
| 9T3752 | 108 VALVE-CHECK | 1 | |
| 1125736 | 109 HOSE AS | 1 | |
| 6V8556 | 110 NUT (1-3/16-12-THD) | 1 | |
| 6D1641 | 111 CLIP (LOOP) | 2 | |
| 6V8941 | 112 REDUCER | 1 | |
| 9X8250 | 116 CLIP (LOOP) | 1 | |
| 1405856 | 117 HOSE AS | 1 |
